示例

在开发 TaskFlow 的过程中，团队努力确保各种概念都通过相关示例进行解释。以下是一些精选的示例，供您入门（按感知复杂度排序）

要探索更多示例，请查看 TaskFlow 示例 目录中的 源代码树。

注意

如果提供的示例不能令人满意（或未达到您的标准），欢迎并非常感谢您贡献以帮助改进它们。示例的质量越高、越清晰，对每个人就越好、越有用。

Hello world

注意

完整源代码位于 hello_world。

import os
import sys

logging.basicConfig(level=logging.ERROR)

top_dir = os.path.abspath(os.path.join(os.path.dirname(__file__),
                                       os.pardir,
                                       os.pardir))
sys.path.insert(0, top_dir)

from taskflow import engines
from taskflow.patterns import linear_flow as lf
from taskflow.patterns import unordered_flow as uf
from taskflow import task


# INTRO: This is the defacto hello world equivalent for taskflow; it shows how
# an overly simplistic workflow can be created that runs using different
# engines using different styles of execution (all can be used to run in
# parallel if a workflow is provided that is parallelizable).

class PrinterTask(task.Task):
    def __init__(self, name, show_name=True, inject=None):
        super().__init__(name, inject=inject)
        self._show_name = show_name

    def execute(self, output):
        if self._show_name:
            print("{}: {}".format(self.name, output))
        else:
            print(output)


# This will be the work that we want done, which for this example is just to
# print 'hello world' (like a song) using different tasks and different
# execution models.
song = lf.Flow("beats")

# Unordered flows when ran can be ran in parallel; and a chorus is everyone
# singing at once of course!
hi_chorus = uf.Flow('hello')
world_chorus = uf.Flow('world')
for (name, hello, world) in [('bob', 'hello', 'world'),
                             ('joe', 'hellooo', 'worllllld'),
                             ('sue', "helloooooo!", 'wooorllld!')]:
    hi_chorus.add(PrinterTask("%s@hello" % name,
                              # This will show up to the execute() method of
                              # the task as the argument named 'output' (which
                              # will allow us to print the character we want).
                              inject={'output': hello}))
    world_chorus.add(PrinterTask("%s@world" % name,
                                 inject={'output': world}))

# The composition starts with the conductor and then runs in sequence with
# the chorus running in parallel, but no matter what the 'hello' chorus must
# always run before the 'world' chorus (otherwise the world will fall apart).
song.add(PrinterTask("conductor@begin",
                     show_name=False, inject={'output': "*ding*"}),
         hi_chorus,
         world_chorus,
         PrinterTask("conductor@end",
                     show_name=False, inject={'output': "*dong*"}))

# Run in parallel using eventlet green threads...
try:
    import eventlet as _eventlet  # noqa
except ImportError:
    # No eventlet currently active, skip running with it...
    pass
else:
    print("-- Running in parallel using eventlet --")
    e = engines.load(song, executor='greenthreaded', engine='parallel',
                     max_workers=1)
    e.run()


# Run in parallel using real threads...
print("-- Running in parallel using threads --")
e = engines.load(song, executor='threaded', engine='parallel',
                 max_workers=1)
e.run()


# Run in parallel using external processes...
print("-- Running in parallel using processes --")
e = engines.load(song, executor='processes', engine='parallel',
                 max_workers=1)
e.run()


# Run serially (aka, if the workflow could have been ran in parallel, it will
# not be when ran in this mode)...
print("-- Running serially --")
e = engines.load(song, engine='serial')
e.run()
print("-- Statistics gathered --")
print(e.statistics)

在任务之间传递值

注意

完整源代码位于 simple_linear_pass。

import os
import sys

logging.basicConfig(level=logging.ERROR)

self_dir = os.path.abspath(os.path.dirname(__file__))
top_dir = os.path.abspath(os.path.join(os.path.dirname(__file__),
                                       os.pardir,
                                       os.pardir))
sys.path.insert(0, top_dir)
sys.path.insert(0, self_dir)

from taskflow import engines
from taskflow.patterns import linear_flow
from taskflow import task

# INTRO: This example shows how a task (in a linear/serial workflow) can
# produce an output that can be then consumed/used by a downstream task.


class TaskA(task.Task):
    default_provides = 'a'

    def execute(self):
        print("Executing '%s'" % (self.name))
        return 'a'


class TaskB(task.Task):
    def execute(self, a):
        print("Executing '%s'" % (self.name))
        print("Got input '%s'" % (a))


print("Constructing...")
wf = linear_flow.Flow("pass-from-to")
wf.add(TaskA('a'), TaskB('b'))

print("Loading...")
e = engines.load(wf)

print("Compiling...")
e.compile()

print("Preparing...")
e.prepare()

print("Running...")
e.run()

print("Done...")

使用监听器

注意

完整源代码位于 echo_listener。

import os
import sys

logging.basicConfig(level=logging.DEBUG)

top_dir = os.path.abspath(os.path.join(os.path.dirname(__file__),
                                       os.pardir,
                                       os.pardir))
sys.path.insert(0, top_dir)

from taskflow import engines
from taskflow.listeners import logging as logging_listener
from taskflow.patterns import linear_flow as lf
from taskflow import task

# INTRO: This example walks through a miniature workflow which will do a
# simple echo operation; during this execution a listener is associated with
# the engine to receive all notifications about what the flow has performed,
# this example dumps that output to the stdout for viewing (at debug level
# to show all the information which is possible).


class Echo(task.Task):
    def execute(self):
        print(self.name)


# Generate the work to be done (but don't do it yet).
wf = lf.Flow('abc')
wf.add(Echo('a'))
wf.add(Echo('b'))
wf.add(Echo('c'))

# This will associate the listener with the engine (the listener
# will automatically register for notifications with the engine and deregister
# when the context is exited).
e = engines.load(wf)
with logging_listener.DynamicLoggingListener(e):
    e.run()

使用监听器（监听电话）

注意

完整源代码位于 simple_linear_listening。

import os
import sys

logging.basicConfig(level=logging.ERROR)

top_dir = os.path.abspath(os.path.join(os.path.dirname(__file__),
                                       os.pardir,
                                       os.pardir))
sys.path.insert(0, top_dir)

import taskflow.engines
from taskflow.patterns import linear_flow as lf
from taskflow import task
from taskflow.types import notifier

ANY = notifier.Notifier.ANY

# INTRO: In this example we create two tasks (this time as functions instead
# of task subclasses as in the simple_linear.py example), each of which ~calls~
# a given ~phone~ number (provided as a function input) in a linear fashion
# (one after the other).
#
# For a workflow which is serial this shows an extremely simple way
# of structuring your tasks (the code that does the work) into a linear
# sequence (the flow) and then passing the work off to an engine, with some
# initial data to be ran in a reliable manner.
#
# This example shows a basic usage of the taskflow structures without involving
# the complexity of persistence. Using the structures that taskflow provides
# via tasks and flows makes it possible for you to easily at a later time
# hook in a persistence layer (and then gain the functionality that offers)
# when you decide the complexity of adding that layer in is 'worth it' for your
# applications usage pattern (which some applications may not need).
#
# It **also** adds on to the simple_linear.py example by adding a set of
# callback functions which the engine will call when a flow state transition
# or task state transition occurs. These types of functions are useful for
# updating task or flow progress, or for debugging, sending notifications to
# external systems, or for other yet unknown future usage that you may create!


def call_jim(context):
    print("Calling jim.")
    print("Context = %s" % (sorted(context.items(), key=lambda x: x[0])))


def call_joe(context):
    print("Calling joe.")
    print("Context = %s" % (sorted(context.items(), key=lambda x: x[0])))


def flow_watch(state, details):
    print('Flow => %s' % state)


def task_watch(state, details):
    print('Task {} => {}'.format(details.get('task_name'), state))


# Wrap your functions into a task type that knows how to treat your functions
# as tasks. There was previous work done to just allow a function to be
# directly passed, but in python 3.0 there is no easy way to capture an
# instance method, so this wrapping approach was decided upon instead which
# can attach to instance methods (if that's desired).
flow = lf.Flow("Call-them")
flow.add(task.FunctorTask(execute=call_jim))
flow.add(task.FunctorTask(execute=call_joe))

# Now load (but do not run) the flow using the provided initial data.
engine = taskflow.engines.load(flow, store={
    'context': {
        "joe_number": 444,
        "jim_number": 555,
    }
})

# This is where we attach our callback functions to the 2 different
# notification objects that an engine exposes. The usage of a ANY (kleene star)
# here means that we want to be notified on all state changes, if you want to
# restrict to a specific state change, just register that instead.
engine.notifier.register(ANY, flow_watch)
engine.atom_notifier.register(ANY, task_watch)

# And now run!
engine.run()

转储内存后端

注意

完整源代码位于 dump_memory_backend。

import os
import sys

logging.basicConfig(level=logging.ERROR)

self_dir = os.path.abspath(os.path.dirname(__file__))
top_dir = os.path.abspath(os.path.join(os.path.dirname(__file__),
                                       os.pardir,
                                       os.pardir))
sys.path.insert(0, top_dir)
sys.path.insert(0, self_dir)

from taskflow import engines
from taskflow.patterns import linear_flow as lf
from taskflow import task

# INTRO: in this example we create a dummy flow with a dummy task, and run
# it using a in-memory backend and pre/post run we dump out the contents
# of the in-memory backends tree structure (which can be quite useful to
# look at for debugging or other analysis).


class PrintTask(task.Task):
    def execute(self):
        print("Running '%s'" % self.name)

# Make a little flow and run it...
f = lf.Flow('root')
for alpha in ['a', 'b', 'c']:
    f.add(PrintTask(alpha))

e = engines.load(f)
e.compile()
e.prepare()

# After prepare the storage layer + backend can now be accessed safely...
backend = e.storage.backend

print("----------")
print("Before run")
print("----------")
print(backend.memory.pformat())
print("----------")

e.run()

print("---------")
print("After run")
print("---------")
for path in backend.memory.ls_r(backend.memory.root_path, absolute=True):
    value = backend.memory[path]
    if value:
        print("{} -> {}".format(path, value))
    else:
        print("%s" % (path))

拨打电话

注意

完整源代码位于 simple_linear。

import os
import sys

logging.basicConfig(level=logging.ERROR)

top_dir = os.path.abspath(os.path.join(os.path.dirname(__file__),
                                       os.pardir,
                                       os.pardir))
sys.path.insert(0, top_dir)

import taskflow.engines
from taskflow.patterns import linear_flow as lf
from taskflow import task

# INTRO: In this example we create two tasks, each of which ~calls~ a given
# ~phone~ number (provided as a function input) in a linear fashion (one after
# the other). For a workflow which is serial this shows a extremely simple way
# of structuring your tasks (the code that does the work) into a linear
# sequence (the flow) and then passing the work off to an engine, with some
# initial data to be ran in a reliable manner.
#
# NOTE(harlowja): This example shows a basic usage of the taskflow structures
# without involving the complexity of persistence. Using the structures that
# taskflow provides via tasks and flows makes it possible for you to easily at
# a later time hook in a persistence layer (and then gain the functionality
# that offers) when you decide the complexity of adding that layer in
# is 'worth it' for your application's usage pattern (which certain
# applications may not need).


class CallJim(task.Task):
    def execute(self, jim_number, *args, **kwargs):
        print("Calling jim %s." % jim_number)


class CallJoe(task.Task):
    def execute(self, joe_number, *args, **kwargs):
        print("Calling joe %s." % joe_number)


# Create your flow and associated tasks (the work to be done).
flow = lf.Flow('simple-linear').add(
    CallJim(),
    CallJoe()
)

# Now run that flow using the provided initial data (store below).
taskflow.engines.run(flow, store=dict(joe_number=444,
                                      jim_number=555))

拨打电话（自动回滚）

注意

完整源代码位于 reverting_linear。

import os
import sys

logging.basicConfig(level=logging.ERROR)

top_dir = os.path.abspath(os.path.join(os.path.dirname(__file__),
                                       os.pardir,
                                       os.pardir))
sys.path.insert(0, top_dir)

import taskflow.engines
from taskflow.patterns import linear_flow as lf
from taskflow import task

# INTRO: In this example we create three tasks, each of which ~calls~ a given
# number (provided as a function input), one of those tasks *fails* calling a
# given number (the suzzie calling); this causes the workflow to enter the
# reverting process, which activates the revert methods of the previous two
# phone ~calls~.
#
# This simulated calling makes it appear like all three calls occur or all
# three don't occur (transaction-like capabilities). No persistence layer is
# used here so reverting and executing will *not* be tolerant of process
# failure.


class CallJim(task.Task):
    def execute(self, jim_number, *args, **kwargs):
        print("Calling jim %s." % jim_number)

    def revert(self, jim_number, *args, **kwargs):
        print("Calling %s and apologizing." % jim_number)


class CallJoe(task.Task):
    def execute(self, joe_number, *args, **kwargs):
        print("Calling joe %s." % joe_number)

    def revert(self, joe_number, *args, **kwargs):
        print("Calling %s and apologizing." % joe_number)


class CallSuzzie(task.Task):
    def execute(self, suzzie_number, *args, **kwargs):
        raise OSError("Suzzie not home right now.")


# Create your flow and associated tasks (the work to be done).
flow = lf.Flow('simple-linear').add(
    CallJim(),
    CallJoe(),
    CallSuzzie()
)

try:
    # Now run that flow using the provided initial data (store below).
    taskflow.engines.run(flow, store=dict(joe_number=444,
                                          jim_number=555,
                                          suzzie_number=666))
except Exception as e:
    # NOTE(harlowja): This exception will be the exception that came out of the
    # 'CallSuzzie' task instead of a different exception, this is useful since
    # typically surrounding code wants to handle the original exception and not
    # a wrapped or altered one.
    #
    # *WARNING* If this flow was multi-threaded and multiple active tasks threw
    # exceptions then the above exception would be wrapped into a combined
    # exception (the object has methods to iterate over the contained
    # exceptions). See: exceptions.py and the class 'WrappedFailure' to look at
    # how to deal with multiple tasks failing while running.
    #
    # You will also note that this is not a problem in this case since no
    # parallelism is involved; this is ensured by the usage of a linear flow
    # and the default engine type which is 'serial' vs being 'parallel'.
    print("Flow failed: %s" % e)

制造汽车

注意

完整源代码位于 build_a_car。

import os
import sys


logging.basicConfig(level=logging.ERROR)

top_dir = os.path.abspath(os.path.join(os.path.dirname(__file__),
                                       os.pardir,
                                       os.pardir))
sys.path.insert(0, top_dir)


import taskflow.engines
from taskflow.patterns import graph_flow as gf
from taskflow.patterns import linear_flow as lf
from taskflow import task
from taskflow.types import notifier

ANY = notifier.Notifier.ANY

import example_utils as eu  # noqa


# INTRO: This example shows how a graph flow and linear flow can be used
# together to execute dependent & non-dependent tasks by going through the
# steps required to build a simplistic car (an assembly line if you will). It
# also shows how raw functions can be wrapped into a task object instead of
# being forced to use the more *heavy* task base class. This is useful in
# scenarios where pre-existing code has functions that you easily want to
# plug-in to taskflow, without requiring a large amount of code changes.


def build_frame():
    return 'steel'


def build_engine():
    return 'honda'


def build_doors():
    return '2'


def build_wheels():
    return '4'


# These just return true to indiciate success, they would in the real work
# do more than just that.

def install_engine(frame, engine):
    return True


def install_doors(frame, windows_installed, doors):
    return True


def install_windows(frame, doors):
    return True


def install_wheels(frame, engine, engine_installed, wheels):
    return True


def trash(**kwargs):
    eu.print_wrapped("Throwing away pieces of car!")


def startup(**kwargs):
    # If you want to see the rollback function being activated try uncommenting
    # the following line.
    #
    # raise ValueError("Car not verified")
    return True


def verify(spec, **kwargs):
    # If the car is not what we ordered throw away the car (trigger reversion).
    for key, value in kwargs.items():
        if spec[key] != value:
            raise Exception("Car doesn't match spec!")
    return True


# These two functions connect into the state transition notification emission
# points that the engine outputs, they can be used to log state transitions
# that are occurring, or they can be used to suspend the engine (or perform
# other useful activities).
def flow_watch(state, details):
    print('Flow => %s' % state)


def task_watch(state, details):
    print('Task {} => {}'.format(details.get('task_name'), state))


flow = lf.Flow("make-auto").add(
    task.FunctorTask(startup, revert=trash, provides='ran'),
    # A graph flow allows automatic dependency based ordering, the ordering
    # is determined by analyzing the symbols required and provided and ordering
    # execution based on a functioning order (if one exists).
    gf.Flow("install-parts").add(
        task.FunctorTask(build_frame, provides='frame'),
        task.FunctorTask(build_engine, provides='engine'),
        task.FunctorTask(build_doors, provides='doors'),
        task.FunctorTask(build_wheels, provides='wheels'),
        # These *_installed outputs allow for other tasks to depend on certain
        # actions being performed (aka the components were installed), another
        # way to do this is to link() the tasks manually instead of creating
        # an 'artificial' data dependency that accomplishes the same goal the
        # manual linking would result in.
        task.FunctorTask(install_engine, provides='engine_installed'),
        task.FunctorTask(install_doors, provides='doors_installed'),
        task.FunctorTask(install_windows, provides='windows_installed'),
        task.FunctorTask(install_wheels, provides='wheels_installed')),
    task.FunctorTask(verify, requires=['frame',
                                       'engine',
                                       'doors',
                                       'wheels',
                                       'engine_installed',
                                       'doors_installed',
                                       'windows_installed',
                                       'wheels_installed']))

# This dictionary will be provided to the tasks as a specification for what
# the tasks should produce, in this example this specification will influence
# what those tasks do and what output they create. Different tasks depend on
# different information from this specification, all of which will be provided
# automatically by the engine to those tasks.
spec = {
    "frame": 'steel',
    "engine": 'honda',
    "doors": '2',
    "wheels": '4',
    # These are used to compare the result product, a car without the pieces
    # installed is not a car after all.
    "engine_installed": True,
    "doors_installed": True,
    "windows_installed": True,
    "wheels_installed": True,
}


engine = taskflow.engines.load(flow, store={'spec': spec.copy()})

# This registers all (ANY) state transitions to trigger a call to the
# flow_watch function for flow state transitions, and registers the
# same all (ANY) state transitions for task state transitions.
engine.notifier.register(ANY, flow_watch)
engine.atom_notifier.register(ANY, task_watch)

eu.print_wrapped("Building a car")
engine.run()

# Alter the specification and ensure that the reverting logic gets triggered
# since the resultant car that will be built by the build_wheels function will
# build a car with 4 doors only (not 5), this will cause the verification
# task to mark the car that is produced as not matching the desired spec.
spec['doors'] = 5

engine = taskflow.engines.load(flow, store={'spec': spec.copy()})
engine.notifier.register(ANY, flow_watch)
engine.atom_notifier.register(ANY, task_watch)

eu.print_wrapped("Building a wrong car that doesn't match specification")
try:
    engine.run()
except Exception as e:
    eu.print_wrapped("Flow failed: %s" % e)

迭代字母表（使用进程）

注意

完整源代码位于 alphabet_soup。

import functools
import logging
import os
import string
import sys
import time

logging.basicConfig(level=logging.ERROR)

self_dir = os.path.abspath(os.path.dirname(__file__))
top_dir = os.path.abspath(os.path.join(os.path.dirname(__file__),
                                       os.pardir,
                                       os.pardir))
sys.path.insert(0, top_dir)
sys.path.insert(0, self_dir)

from taskflow import engines
from taskflow import exceptions
from taskflow.patterns import linear_flow
from taskflow import task


# In this example we show how a simple linear set of tasks can be executed
# using local processes (and not threads or remote workers) with minimal (if
# any) modification to those tasks to make them safe to run in this mode.
#
# This is useful since it allows further scaling up your workflows when thread
# execution starts to become a bottleneck (which it can start to be due to the
# GIL in python). It also offers a intermediary scalable runner that can be
# used when the scale and/or setup of remote workers is not desirable.


def progress_printer(task, event_type, details):
    # This callback, attached to each task will be called in the local
    # process (not the child processes)...
    progress = details.pop('progress')
    progress = int(progress * 100.0)
    print("Task '%s' reached %d%% completion" % (task.name, progress))


class AlphabetTask(task.Task):
    # Second delay between each progress part.
    _DELAY = 0.1

    # This task will run in X main stages (each with a different progress
    # report that will be delivered back to the running process...). The
    # initial 0% and 100% are triggered automatically by the engine when
    # a task is started and finished (so that's why those are not emitted
    # here).
    _PROGRESS_PARTS = [fractions.Fraction("%s/5" % x) for x in range(1, 5)]

    def execute(self):
        for p in self._PROGRESS_PARTS:
            self.update_progress(p)
            time.sleep(self._DELAY)


print("Constructing...")
soup = linear_flow.Flow("alphabet-soup")
for letter in string.ascii_lowercase:
    abc = AlphabetTask(letter)
    abc.notifier.register(task.EVENT_UPDATE_PROGRESS,
                          functools.partial(progress_printer, abc))
    soup.add(abc)
try:
    print("Loading...")
    e = engines.load(soup, engine='parallel', executor='processes')
    print("Compiling...")
    e.compile()
    print("Preparing...")
    e.prepare()
    print("Running...")
    e.run()
    print("Done: %s" % e.statistics)
except exceptions.NotImplementedError as e:
    print(e)

观察执行时间

注意

完整源代码位于 timing_listener。

import os
import random
import sys
import time

logging.basicConfig(level=logging.ERROR)

top_dir = os.path.abspath(os.path.join(os.path.dirname(__file__),
                                       os.pardir,
                                       os.pardir))
sys.path.insert(0, top_dir)

from taskflow import engines
from taskflow.listeners import timing
from taskflow.patterns import linear_flow as lf
from taskflow import task

# INTRO: in this example we will attach a listener to an engine
# and have variable run time tasks run and show how the listener will print
# out how long those tasks took (when they started and when they finished).
#
# This shows how timing metrics can be gathered (or attached onto an engine)
# after a workflow has been constructed, making it easy to gather metrics
# dynamically for situations where this kind of information is applicable (or
# even adding this information on at a later point in the future when your
# application starts to slow down).


class VariableTask(task.Task):
    def __init__(self, name):
        super().__init__(name)
        self._sleepy_time = random.random()

    def execute(self):
        time.sleep(self._sleepy_time)


f = lf.Flow('root')
f.add(VariableTask('a'), VariableTask('b'), VariableTask('c'))
e = engines.load(f)
with timing.PrintingDurationListener(e):
    e.run()

距离计算器

注意

完整源代码位于 distance_calculator

import math
import os
import sys

top_dir = os.path.abspath(os.path.join(os.path.dirname(__file__),
                                       os.pardir,
                                       os.pardir))
sys.path.insert(0, top_dir)

from taskflow import engines
from taskflow.patterns import linear_flow
from taskflow import task

# INTRO: This shows how to use a tasks/atoms ability to take requirements from
# its execute functions default parameters and shows how to provide those
# via different methods when needed, to influence those parameters to in
# this case calculate the distance between two points in 2D space.

# A 2D point.
Point = collections.namedtuple("Point", "x,y")


def is_near(val, expected, tolerance=0.001):
    # Floats don't really provide equality...
    if val > (expected + tolerance):
        return False
    if val < (expected - tolerance):
        return False
    return True


class DistanceTask(task.Task):
    # See: http://en.wikipedia.org/wiki/Distance#Distance_in_Euclidean_space

    default_provides = 'distance'

    def execute(self, a=Point(0, 0), b=Point(0, 0)):
        return math.sqrt(math.pow(b.x - a.x, 2) + math.pow(b.y - a.y, 2))


if __name__ == '__main__':
    # For these we rely on the execute() methods points by default being
    # at the origin (and we override it with store values when we want) at
    # execution time (which then influences what is calculated).
    any_distance = linear_flow.Flow("origin").add(DistanceTask())
    results = engines.run(any_distance)
    print(results)
    print("{} is near-enough to {}: {}".format(
        results['distance'], 0.0, is_near(results['distance'], 0.0)))

    results = engines.run(any_distance, store={'a': Point(1, 1)})
    print(results)
    print("{} is near-enough to {}: {}".format(
        results['distance'], 1.4142, is_near(results['distance'], 1.4142)))

    results = engines.run(any_distance, store={'a': Point(10, 10)})
    print(results)
    print("{} is near-enough to {}: {}".format(
        results['distance'], 14.14199, is_near(results['distance'], 14.14199)))

    results = engines.run(any_distance,
                          store={'a': Point(5, 5), 'b': Point(10, 10)})
    print(results)
    print("{} is near-enough to {}: {}".format(
        results['distance'], 7.07106, is_near(results['distance'], 7.07106)))

    # For this we use the ability to override at task creation time the
    # optional arguments so that we don't need to continue to send them
    # in via the 'store' argument like in the above (and we fix the new
    # starting point 'a' at (10, 10) instead of (0, 0)...

    ten_distance = linear_flow.Flow("ten")
    ten_distance.add(DistanceTask(inject={'a': Point(10, 10)}))
    results = engines.run(ten_distance, store={'b': Point(10, 10)})
    print(results)
    print("{} is near-enough to {}: {}".format(
        results['distance'], 0.0, is_near(results['distance'], 0.0)))

    results = engines.run(ten_distance)
    print(results)
    print("{} is near-enough to {}: {}".format(
        results['distance'], 14.14199, is_near(results['distance'], 14.14199)))

表格乘法器（并行）

注意

完整源代码位于 parallel_table_multiply

import logging
import os
import random
import sys

logging.basicConfig(level=logging.ERROR)

top_dir = os.path.abspath(os.path.join(os.path.dirname(__file__),
                                       os.pardir,
                                       os.pardir))
sys.path.insert(0, top_dir)

import futurist

from taskflow import engines
from taskflow.patterns import unordered_flow as uf
from taskflow import task

# INTRO: This example walks through a miniature workflow which does a parallel
# table modification where each row in the table gets adjusted by a thread, or
# green thread (if eventlet is available) in parallel and then the result
# is reformed into a new table and some verifications are performed on it
# to ensure everything went as expected.


MULTIPLER = 10


class RowMultiplier(task.Task):
    """Performs a modification of an input row, creating a output row."""

    def __init__(self, name, index, row, multiplier):
        super().__init__(name=name)
        self.index = index
        self.multiplier = multiplier
        self.row = row

    def execute(self):
        return [r * self.multiplier for r in self.row]


def make_flow(table):
    # This creation will allow for parallel computation (since the flow here
    # is specifically unordered; and when things are unordered they have
    # no dependencies and when things have no dependencies they can just be
    # ran at the same time, limited in concurrency by the executor or max
    # workers of that executor...)
    f = uf.Flow("root")
    for i, row in enumerate(table):
        f.add(RowMultiplier("m-%s" % i, i, row, MULTIPLER))
    # NOTE(harlowja): at this point nothing has ran, the above is just
    # defining what should be done (but not actually doing it) and associating
    # an ordering dependencies that should be enforced (the flow pattern used
    # forces this), the engine in the later main() function will actually
    # perform this work...
    return f


def main():
    if len(sys.argv) == 2:
        tbl = []
        with open(sys.argv[1], 'rb') as fh:
            reader = csv.reader(fh)
            for row in reader:
                tbl.append([float(r) if r else 0.0 for r in row])
    else:
        # Make some random table out of thin air...
        tbl = []
        cols = random.randint(1, 100)
        rows = random.randint(1, 100)
        for _i in range(0, rows):
            row = []
            for _j in range(0, cols):
                row.append(random.random())
            tbl.append(row)

    # Generate the work to be done.
    f = make_flow(tbl)

    # Now run it (using the specified executor)...
    try:
        executor = futurist.GreenThreadPoolExecutor(max_workers=5)
    except RuntimeError:
        # No eventlet currently active, use real threads instead.
        executor = futurist.ThreadPoolExecutor(max_workers=5)
    try:
        e = engines.load(f, engine='parallel', executor=executor)
        for st in e.run_iter():
            print(st)
    finally:
        executor.shutdown()

    # Find the old rows and put them into place...
    #
    # TODO(harlowja): probably easier just to sort instead of search...
    computed_tbl = []
    for i in range(0, len(tbl)):
        for t in f:
            if t.index == i:
                computed_tbl.append(e.storage.get(t.name))

    # Do some basic validation (which causes the return code of this process
    # to be different if things were not as expected...)
    if len(computed_tbl) != len(tbl):
        return 1
    else:
        return 0


if __name__ == "__main__":
    sys.exit(main())

线性方程求解器（显式依赖项）

注意

完整源代码位于 calculate_linear。

import os
import sys

logging.basicConfig(level=logging.ERROR)

top_dir = os.path.abspath(os.path.join(os.path.dirname(__file__),
                                       os.pardir,
                                       os.pardir))
sys.path.insert(0, top_dir)

import taskflow.engines
from taskflow.patterns import linear_flow as lf
from taskflow import task


# INTRO: In this example a linear flow is used to group four tasks to calculate
# a value. A single added task is used twice, showing how this can be done
# and the twice added task takes in different bound values. In the first case
# it uses default parameters ('x' and 'y') and in the second case arguments
# are bound with ('z', 'd') keys from the engines internal storage mechanism.
#
# A multiplier task uses a binding that another task also provides, but this
# example explicitly shows that 'z' parameter is bound with 'a' key
# This shows that if a task depends on a key named the same as a key provided
# from another task the name can be remapped to take the desired key from a
# different origin.


# This task provides some values from as a result of execution, this can be
# useful when you want to provide values from a static set to other tasks that
# depend on those values existing before those tasks can run.
#
# NOTE(harlowja): this usage is *depreciated* in favor of a simpler mechanism
# that just provides those values on engine running by prepopulating the
# storage backend before your tasks are ran (which accomplishes a similar goal
# in a more uniform manner).
class Provider(task.Task):

    def __init__(self, name, *args, **kwargs):
        super().__init__(name=name, **kwargs)
        self._provide = args

    def execute(self):
        return self._provide


# This task adds two input variables and returns the result.
#
# Note that since this task does not have a revert() function (since addition
# is a stateless operation) there are no side-effects that this function needs
# to undo if some later operation fails.
class Adder(task.Task):
    def execute(self, x, y):
        return x + y


# This task multiplies an input variable by a multiplier and returns the
# result.
#
# Note that since this task does not have a revert() function (since
# multiplication is a stateless operation) and there are no side-effects that
# this function needs to undo if some later operation fails.
class Multiplier(task.Task):
    def __init__(self, name, multiplier, provides=None, rebind=None):
        super().__init__(name=name, provides=provides,
                         rebind=rebind)
        self._multiplier = multiplier

    def execute(self, z):
        return z * self._multiplier


# Note here that the ordering is established so that the correct sequences
# of operations occurs where the adding and multiplying is done according
# to the expected and typical mathematical model. A graph flow could also be
# used here to automatically infer & ensure the correct ordering.
flow = lf.Flow('root').add(
    # Provide the initial values for other tasks to depend on.
    #
    # x = 2, y = 3, d = 5
    Provider("provide-adder", 2, 3, 5, provides=('x', 'y', 'd')),
    # z = x+y = 5
    Adder("add-1", provides='z'),
    # a = z+d = 10
    Adder("add-2", provides='a', rebind=['z', 'd']),
    # Calculate 'r = a*3 = 30'
    #
    # Note here that the 'z' argument of the execute() function will not be
    # bound to the 'z' variable provided from the above 'provider' object but
    # instead the 'z' argument will be taken from the 'a' variable provided
    # by the second add-2 listed above.
    Multiplier("multi", 3, provides='r', rebind={'z': 'a'})
)

# The result here will be all results (from all tasks) which is stored in an
# in-memory storage location that backs this engine since it is not configured
# with persistence storage.
results = taskflow.engines.run(flow)
print(results)

线性方程求解器（推断依赖项）

来源： graph_flow.py

import os
import sys

logging.basicConfig(level=logging.ERROR)

top_dir = os.path.abspath(os.path.join(os.path.dirname(__file__),
                                       os.pardir,
                                       os.pardir))
sys.path.insert(0, top_dir)

import taskflow.engines
from taskflow.patterns import graph_flow as gf
from taskflow.patterns import linear_flow as lf
from taskflow import task


# In this example there are complex *inferred* dependencies between tasks that
# are used to perform a simple set of linear equations.
#
# As you will see below the tasks just define what they require as input
# and produce as output (named values). Then the user doesn't care about
# ordering the tasks (in this case the tasks calculate pieces of the overall
# equation).
#
# As you will notice a graph flow resolves dependencies automatically using the
# tasks symbol requirements and provided symbol values and no orderin
# dependency has to be manually created.
#
# Also notice that flows of any types can be nested into a graph flow; showing
# that subflow dependencies (and associated ordering) will be inferred too.


class Adder(task.Task):

    def execute(self, x, y):
        return x + y


flow = gf.Flow('root').add(
    lf.Flow('nested_linear').add(
        # x2 = y3+y4 = 12
        Adder("add2", provides='x2', rebind=['y3', 'y4']),
        # x1 = y1+y2 = 4
        Adder("add1", provides='x1', rebind=['y1', 'y2'])
    ),
    # x5 = x1+x3 = 20
    Adder("add5", provides='x5', rebind=['x1', 'x3']),
    # x3 = x1+x2 = 16
    Adder("add3", provides='x3', rebind=['x1', 'x2']),
    # x4 = x2+y5 = 21
    Adder("add4", provides='x4', rebind=['x2', 'y5']),
    # x6 = x5+x4 = 41
    Adder("add6", provides='x6', rebind=['x5', 'x4']),
    # x7 = x6+x6 = 82
    Adder("add7", provides='x7', rebind=['x6', 'x6']))

# Provide the initial variable inputs using a storage dictionary.
store = {
    "y1": 1,
    "y2": 3,
    "y3": 5,
    "y4": 7,
    "y5": 9,
}

# This is the expected values that should be created.
unexpected = 0
expected = [
    ('x1', 4),
    ('x2', 12),
    ('x3', 16),
    ('x4', 21),
    ('x5', 20),
    ('x6', 41),
    ('x7', 82),
]

result = taskflow.engines.run(
    flow, engine='serial', store=store)

print("Single threaded engine result %s" % result)
for (name, value) in expected:
    actual = result.get(name)
    if actual != value:
        sys.stderr.write("{} != {}\n".format(actual, value))
        unexpected += 1

result = taskflow.engines.run(
    flow, engine='parallel', store=store)

print("Multi threaded engine result %s" % result)
for (name, value) in expected:
    actual = result.get(name)
    if actual != value:
        sys.stderr.write("{} != {}\n".format(actual, value))
        unexpected += 1

if unexpected:
    sys.exit(1)

线性方程求解器（并行）

注意

完整源代码位于 calculate_in_parallel

import os
import sys

logging.basicConfig(level=logging.ERROR)

top_dir = os.path.abspath(os.path.join(os.path.dirname(__file__),
                                       os.pardir,
                                       os.pardir))
sys.path.insert(0, top_dir)

import taskflow.engines
from taskflow.patterns import linear_flow as lf
from taskflow.patterns import unordered_flow as uf
from taskflow import task

# INTRO: These examples show how a linear flow and an unordered flow can be
# used together to execute calculations in parallel and then use the
# result for the next task/s. The adder task is used for all calculations
# and argument bindings are used to set correct parameters for each task.


# This task provides some values from as a result of execution, this can be
# useful when you want to provide values from a static set to other tasks that
# depend on those values existing before those tasks can run.
#
# NOTE(harlowja): this usage is *depreciated* in favor of a simpler mechanism
# that provides those values on engine running by prepopulating the storage
# backend before your tasks are ran (which accomplishes a similar goal in a
# more uniform manner).
class Provider(task.Task):
    def __init__(self, name, *args, **kwargs):
        super().__init__(name=name, **kwargs)
        self._provide = args

    def execute(self):
        return self._provide


# This task adds two input variables and returns the result of that addition.
#
# Note that since this task does not have a revert() function (since addition
# is a stateless operation) there are no side-effects that this function needs
# to undo if some later operation fails.
class Adder(task.Task):
    def execute(self, x, y):
        return x + y


flow = lf.Flow('root').add(
    # Provide the initial values for other tasks to depend on.
    #
    # x1 = 2, y1 = 3, x2 = 5, x3 = 8
    Provider("provide-adder", 2, 3, 5, 8,
             provides=('x1', 'y1', 'x2', 'y2')),
    # Note here that we define the flow that contains the 2 adders to be an
    # unordered flow since the order in which these execute does not matter,
    # another way to solve this would be to use a graph_flow pattern, which
    # also can run in parallel (since they have no ordering dependencies).
    uf.Flow('adders').add(
        # Calculate 'z1 = x1+y1 = 5'
        #
        # Rebind here means that the execute() function x argument will be
        # satisfied from a previous output named 'x1', and the y argument
        # of execute() will be populated from the previous output named 'y1'
        #
        # The output (result of adding) will be mapped into a variable named
        # 'z1' which can then be refereed to and depended on by other tasks.
        Adder(name="add", provides='z1', rebind=['x1', 'y1']),
        # z2 = x2+y2 = 13
        Adder(name="add-2", provides='z2', rebind=['x2', 'y2']),
    ),
    # r = z1+z2 = 18
    Adder(name="sum-1", provides='r', rebind=['z1', 'z2']))


# The result here will be all results (from all tasks) which is stored in an
# in-memory storage location that backs this engine since it is not configured
# with persistence storage.
result = taskflow.engines.run(flow, engine='parallel')
print(result)

创建卷（并行）

注意

完整源代码位于 create_parallel_volume

import logging
import os
import random
import sys
import time

logging.basicConfig(level=logging.ERROR)

top_dir = os.path.abspath(os.path.join(os.path.dirname(__file__),
                                       os.pardir,
                                       os.pardir))
sys.path.insert(0, top_dir)

from oslo_utils import reflection

from taskflow import engines
from taskflow.listeners import printing
from taskflow.patterns import unordered_flow as uf
from taskflow import task

# INTRO: These examples show how unordered_flow can be used to create a large
# number of fake volumes in parallel (or serially, depending on a constant that
# can be easily changed).


@contextlib.contextmanager
def show_time(name):
    start = time.time()
    yield
    end = time.time()
    print(" -- {} took {:0.3f} seconds".format(name, end - start))


# This affects how many volumes to create and how much time to *simulate*
# passing for that volume to be created.
MAX_CREATE_TIME = 3
VOLUME_COUNT = 5

# This will be used to determine if all the volumes are created in parallel
# or whether the volumes are created serially (in an undefined ordered since
# a unordered flow is used). Note that there is a disconnection between the
# ordering and the concept of parallelism (since unordered items can still be
# ran in a serial ordering). A typical use-case for offering both is to allow
# for debugging using a serial approach, while when running at a larger scale
# one would likely want to use the parallel approach.
#
# If you switch this flag from serial to parallel you can see the overall
# time difference that this causes.
SERIAL = False
if SERIAL:
    engine = 'serial'
else:
    engine = 'parallel'


class VolumeCreator(task.Task):
    def __init__(self, volume_id):
        # Note here that the volume name is composed of the name of the class
        # along with the volume id that is being created, since a name of a
        # task uniquely identifies that task in storage it is important that
        # the name be relevant and identifiable if the task is recreated for
        # subsequent resumption (if applicable).
        #
        # UUIDs are *not* used as they can not be tied back to a previous tasks
        # state on resumption (since they are unique and will vary for each
        # task that is created). A name based off the volume id that is to be
        # created is more easily tied back to the original task so that the
        # volume create can be resumed/revert, and is much easier to use for
        # audit and tracking purposes.
        base_name = reflection.get_callable_name(self)
        super().__init__(name="{}-{}".format(base_name, volume_id))
        self._volume_id = volume_id

    def execute(self):
        print("Making volume %s" % (self._volume_id))
        time.sleep(random.random() * MAX_CREATE_TIME)
        print("Finished making volume %s" % (self._volume_id))


# Assume there is no ordering dependency between volumes.
flow = uf.Flow("volume-maker")
for i in range(0, VOLUME_COUNT):
    flow.add(VolumeCreator(volume_id="vol-%s" % (i)))


# Show how much time the overall engine loading and running takes.
with show_time(name=flow.name.title()):
    eng = engines.load(flow, engine=engine)
    # This context manager automatically adds (and automatically removes) a
    # helpful set of state transition notification printing helper utilities
    # that show you exactly what transitions the engine is going through
    # while running the various volume create tasks.
    with printing.PrintingListener(eng):
        eng.run()

求和映射器和归约器（并行）

注意

完整源代码位于 simple_map_reduce

import os
import sys

logging.basicConfig(level=logging.ERROR)

self_dir = os.path.abspath(os.path.dirname(__file__))
top_dir = os.path.abspath(os.path.join(os.path.dirname(__file__),
                                       os.pardir,
                                       os.pardir))
sys.path.insert(0, top_dir)
sys.path.insert(0, self_dir)

# INTRO: These examples show a simplistic map/reduce implementation where
# a set of mapper(s) will sum a series of input numbers (in parallel) and
# return their individual summed result. A reducer will then use those
# produced values and perform a final summation and this result will then be
# printed (and verified to ensure the calculation was as expected).

from taskflow import engines
from taskflow.patterns import linear_flow
from taskflow.patterns import unordered_flow
from taskflow import task


class SumMapper(task.Task):
    def execute(self, inputs):
        # Sums some set of provided inputs.
        return sum(inputs)


class TotalReducer(task.Task):
    def execute(self, *args, **kwargs):
        # Reduces all mapped summed outputs into a single value.
        total = 0
        for (k, v) in kwargs.items():
            # If any other kwargs was passed in, we don't want to use those
            # in the calculation of the total...
            if k.startswith('reduction_'):
                total += v
        return total


def chunk_iter(chunk_size, upperbound):
    """Yields back chunk size pieces from zero to upperbound - 1."""
    chunk = []
    for i in range(0, upperbound):
        chunk.append(i)
        if len(chunk) == chunk_size:
            yield chunk
            chunk = []


# Upper bound of numbers to sum for example purposes...
UPPER_BOUND = 10000

# How many mappers we want to have.
SPLIT = 10

# How big of a chunk we want to give each mapper.
CHUNK_SIZE = UPPER_BOUND // SPLIT

# This will be the workflow we will compose and run.
w = linear_flow.Flow("root")

# The mappers will run in parallel.
store = {}
provided = []
mappers = unordered_flow.Flow('map')
for i, chunk in enumerate(chunk_iter(CHUNK_SIZE, UPPER_BOUND)):
    mapper_name = 'mapper_%s' % i
    # Give that mapper some information to compute.
    store[mapper_name] = chunk
    # The reducer uses all of the outputs of the mappers, so it needs
    # to be recorded that it needs access to them (under a specific name).
    provided.append("reduction_%s" % i)
    mappers.add(SumMapper(name=mapper_name,
                          rebind={'inputs': mapper_name},
                          provides=provided[-1]))
w.add(mappers)

# The reducer will run last (after all the mappers).
w.add(TotalReducer('reducer', requires=provided))

# Now go!
e = engines.load(w, engine='parallel', store=store, max_workers=4)
print("Running a parallel engine with options: %s" % e.options)
e.run()

# Now get the result the reducer created.
total = e.storage.get('reducer')
print("Calculated result = %s" % total)

# Calculate it manually to verify that it worked...
calc_total = sum(range(0, UPPER_BOUND))
if calc_total != total:
    sys.exit(1)

共享线程池执行器（并行）

注意

完整源代码位于 share_engine_thread

import os
import random
import sys
import time

logging.basicConfig(level=logging.ERROR)

top_dir = os.path.abspath(os.path.join(os.path.dirname(__file__),
                                       os.pardir,
                                       os.pardir))
sys.path.insert(0, top_dir)

import futurist

from taskflow import engines
from taskflow.patterns import unordered_flow as uf
from taskflow import task
from taskflow.utils import threading_utils as tu

# INTRO: in this example we create 2 dummy flow(s) with a 2 dummy task(s), and
# run it using a shared thread pool executor to show how a single executor can
# be used with more than one engine (sharing the execution thread pool between
# them); this allows for saving resources and reusing threads in situations
# where this is benefical.


class DelayedTask(task.Task):
    def __init__(self, name):
        super().__init__(name=name)
        self._wait_for = random.random()

    def execute(self):
        print("Running '{}' in thread '{}'".format(self.name, tu.get_ident()))
        time.sleep(self._wait_for)


f1 = uf.Flow("f1")
f1.add(DelayedTask("f1-1"))
f1.add(DelayedTask("f1-2"))

f2 = uf.Flow("f2")
f2.add(DelayedTask("f2-1"))
f2.add(DelayedTask("f2-2"))

# Run them all using the same futures (thread-pool based) executor...
with futurist.ThreadPoolExecutor() as ex:
    e1 = engines.load(f1, engine='parallel', executor=ex)
    e2 = engines.load(f2, engine='parallel', executor=ex)
    iters = [e1.run_iter(), e2.run_iter()]
    # Iterate over a copy (so we can remove from the source list).
    cloned_iters = list(iters)
    while iters:
        # Run a single 'step' of each iterator, forcing each engine to perform
        # some work, then yield, and repeat until each iterator is consumed
        # and there is no more engine work to be done.
        for it in cloned_iters:
            try:
                next(it)
            except StopIteration:
                try:
                    iters.remove(it)
                except ValueError:
                    pass

存储和发送账单

注意

完整源代码位于 fake_billing

import logging
import os
import sys
import time

logging.basicConfig(level=logging.ERROR)

top_dir = os.path.abspath(os.path.join(os.path.dirname(__file__),
                                       os.pardir,
                                       os.pardir))
sys.path.insert(0, top_dir)

from oslo_utils import uuidutils

from taskflow import engines
from taskflow.listeners import printing
from taskflow.patterns import graph_flow as gf
from taskflow.patterns import linear_flow as lf
from taskflow import task
from taskflow.utils import misc

# INTRO: This example walks through a miniature workflow which simulates
# the reception of an API request, creation of a database entry, driver
# activation (which invokes a 'fake' webservice) and final completion.
#
# This example also shows how a function/object (in this class the url sending)
# that occurs during driver activation can update the progress of a task
# without being aware of the internals of how to do this by associating a
# callback that the url sending can update as the sending progresses from 0.0%
# complete to 100% complete.


class DB:
    def query(self, sql):
        print("Querying with: %s" % (sql))


class UrlCaller:
    def __init__(self):
        self._send_time = 0.5
        self._chunks = 25

    def send(self, url, data, status_cb=None):
        sleep_time = float(self._send_time) / self._chunks
        for i in range(0, len(data)):
            time.sleep(sleep_time)
            # As we send the data, each chunk we 'fake' send will progress
            # the sending progress that much further to 100%.
            if status_cb:
                status_cb(float(i) / len(data))


# Since engines save the output of tasks to a optional persistent storage
# backend resources have to be dealt with in a slightly different manner since
# resources are transient and can *not* be persisted (or serialized). For tasks
# that require access to a set of resources it is a common pattern to provide
# a object (in this case this object) on construction of those tasks via the
# task constructor.
class ResourceFetcher:
    def __init__(self):
        self._db_handle = None
        self._url_handle = None

    @property
    def db_handle(self):
        if self._db_handle is None:
            self._db_handle = DB()
        return self._db_handle

    @property
    def url_handle(self):
        if self._url_handle is None:
            self._url_handle = UrlCaller()
        return self._url_handle


class ExtractInputRequest(task.Task):
    def __init__(self, resources):
        super().__init__(provides="parsed_request")
        self._resources = resources

    def execute(self, request):
        return {
            'user': request.user,
            'user_id': misc.as_int(request.id),
            'request_id': uuidutils.generate_uuid(),
        }


class MakeDBEntry(task.Task):
    def __init__(self, resources):
        super().__init__()
        self._resources = resources

    def execute(self, parsed_request):
        db_handle = self._resources.db_handle
        db_handle.query("INSERT %s INTO mydb" % (parsed_request))

    def revert(self, result, parsed_request):
        db_handle = self._resources.db_handle
        db_handle.query("DELETE %s FROM mydb IF EXISTS" % (parsed_request))


class ActivateDriver(task.Task):
    def __init__(self, resources):
        super().__init__(provides='sent_to')
        self._resources = resources
        self._url = "http://blahblah.com"

    def execute(self, parsed_request):
        print("Sending billing data to %s" % (self._url))
        url_sender = self._resources.url_handle
        # Note that here we attach our update_progress function (which is a
        # function that the engine also 'binds' to) to the progress function
        # that the url sending helper class uses. This allows the task progress
        # to be tied to the url sending progress, which is very useful for
        # downstream systems to be aware of what a task is doing at any time.
        url_sender.send(self._url, json.dumps(parsed_request),
                        status_cb=self.update_progress)
        return self._url

    def update_progress(self, progress, **kwargs):
        # Override the parent method to also print out the status.
        super().update_progress(progress, **kwargs)
        print("{} is {:0.2f}% done".format(self.name, progress * 100))


class DeclareSuccess(task.Task):
    def execute(self, sent_to):
        print("Done!")
        print("All data processed and sent to %s" % (sent_to))


class DummyUser:
    def __init__(self, user, id_):
        self.user = user
        self.id = id_


# Resources (db handles and similar) of course can *not* be persisted so we
# need to make sure that we pass this resource fetcher to the tasks constructor
# so that the tasks have access to any needed resources (the resources are
# lazily loaded so that they are only created when they are used).
resources = ResourceFetcher()
flow = lf.Flow("initialize-me")

# 1. First we extract the api request into a usable format.
# 2. Then we go ahead and make a database entry for our request.
flow.add(ExtractInputRequest(resources), MakeDBEntry(resources))

# 3. Then we activate our payment method and finally declare success.
sub_flow = gf.Flow("after-initialize")
sub_flow.add(ActivateDriver(resources), DeclareSuccess())
flow.add(sub_flow)

# Initially populate the storage with the following request object,
# prepopulating this allows the tasks that dependent on the 'request' variable
# to start processing (in this case this is the ExtractInputRequest task).
store = {
    'request': DummyUser(user="bob", id_="1.35"),
}
eng = engines.load(flow, engine='serial', store=store)

# This context manager automatically adds (and automatically removes) a
# helpful set of state transition notification printing helper utilities
# that show you exactly what transitions the engine is going through
# while running the various billing related tasks.
with printing.PrintingListener(eng):
    eng.run()

暂停工作流并恢复

注意

完整源代码位于 resume_from_backend

import logging
import os
import sys

logging.basicConfig(level=logging.ERROR)

self_dir = os.path.abspath(os.path.dirname(__file__))
top_dir = os.path.abspath(os.path.join(os.path.dirname(__file__),
                                       os.pardir,
                                       os.pardir))
sys.path.insert(0, top_dir)
sys.path.insert(0, self_dir)

from oslo_utils import uuidutils

import taskflow.engines
from taskflow.patterns import linear_flow as lf
from taskflow.persistence import models
from taskflow import task

import example_utils as eu  # noqa

# INTRO: In this example linear_flow is used to group three tasks, one which
# will suspend the future work the engine may do. This suspend engine is then
# discarded and the workflow is reloaded from the persisted data and then the
# workflow is resumed from where it was suspended. This allows you to see how
# to start an engine, have a task stop the engine from doing future work (if
# a multi-threaded engine is being used, then the currently active work is not
# preempted) and then resume the work later.
#
# Usage:
#
#   With a filesystem directory as backend
#
#     python taskflow/examples/resume_from_backend.py
#
#   With ZooKeeper as backend
#
#     python taskflow/examples/resume_from_backend.py \
#       zookeeper://127.0.0.1:2181/taskflow/resume_from_backend/


# UTILITY FUNCTIONS #########################################


def print_task_states(flowdetail, msg):
    eu.print_wrapped(msg)
    print("Flow '{}' state: {}".format(flowdetail.name, flowdetail.state))
    # Sort by these so that our test validation doesn't get confused by the
    # order in which the items in the flow detail can be in.
    items = sorted((td.name, td.version, td.state, td.results)
                   for td in flowdetail)
    for item in items:
        print(" %s==%s: %s, result=%s" % item)


def find_flow_detail(backend, lb_id, fd_id):
    conn = backend.get_connection()
    lb = conn.get_logbook(lb_id)
    return lb.find(fd_id)


# CREATE FLOW ###############################################


class InterruptTask(task.Task):
    def execute(self):
        # DO NOT TRY THIS AT HOME
        engine.suspend()


class TestTask(task.Task):
    def execute(self):
        print('executing %s' % self)
        return 'ok'


def flow_factory():
    return lf.Flow('resume from backend example').add(
        TestTask(name='first'),
        InterruptTask(name='boom'),
        TestTask(name='second'))


# INITIALIZE PERSISTENCE ####################################

with eu.get_backend() as backend:

    # Create a place where the persistence information will be stored.
    book = models.LogBook("example")
    flow_detail = models.FlowDetail("resume from backend example",
                                    uuid=uuidutils.generate_uuid())
    book.add(flow_detail)
    with contextlib.closing(backend.get_connection()) as conn:
        conn.save_logbook(book)

    # CREATE AND RUN THE FLOW: FIRST ATTEMPT ####################

    flow = flow_factory()
    engine = taskflow.engines.load(flow, flow_detail=flow_detail,
                                   book=book, backend=backend)

    print_task_states(flow_detail, "At the beginning, there is no state")
    eu.print_wrapped("Running")
    engine.run()
    print_task_states(flow_detail, "After running")

    # RE-CREATE, RESUME, RUN ####################################

    eu.print_wrapped("Resuming and running again")

    # NOTE(harlowja): reload the flow detail from backend, this will allow us
    # to resume the flow from its suspended state, but first we need to search
    # for the right flow details in the correct logbook where things are
    # stored.
    #
    # We could avoid re-loading the engine and just do engine.run() again, but
    # this example shows how another process may unsuspend a given flow and
    # start it again for situations where this is useful to-do (say the process
    # running the above flow crashes).
    flow2 = flow_factory()
    flow_detail_2 = find_flow_detail(backend, book.uuid, flow_detail.uuid)
    engine2 = taskflow.engines.load(flow2,
                                    flow_detail=flow_detail_2,
                                    backend=backend, book=book)
    engine2.run()
    print_task_states(flow_detail_2, "At the end")

创建虚拟机（可恢复）

注意

完整源代码位于 resume_vm_boot

import hashlib
import logging
import os
import random
import sys
import time

logging.basicConfig(level=logging.ERROR)

self_dir = os.path.abspath(os.path.dirname(__file__))
top_dir = os.path.abspath(os.path.join(os.path.dirname(__file__),
                                       os.pardir,
                                       os.pardir))
sys.path.insert(0, top_dir)
sys.path.insert(0, self_dir)

import futurist
from oslo_utils import uuidutils

from taskflow import engines
from taskflow import exceptions as exc
from taskflow.patterns import graph_flow as gf
from taskflow.patterns import linear_flow as lf
from taskflow.persistence import models
from taskflow import task

import example_utils as eu  # noqa

# INTRO: These examples show how a hierarchy of flows can be used to create a
# vm in a reliable & resumable manner using taskflow + a miniature version of
# what nova does while booting a vm.


@contextlib.contextmanager
def slow_down(how_long=0.5):
    try:
        yield how_long
    finally:
        if len(sys.argv) > 1:
            # Only both to do this if user input provided.
            print("** Ctrl-c me please!!! **")
            time.sleep(how_long)


class PrintText(task.Task):
    """Just inserts some text print outs in a workflow."""
    def __init__(self, print_what, no_slow=False):
        content_hash = hashlib.md5(print_what.encode('utf-8')).hexdigest()[0:8]
        super().__init__(name="Print: %s" % (content_hash))
        self._text = print_what
        self._no_slow = no_slow

    def execute(self):
        if self._no_slow:
            eu.print_wrapped(self._text)
        else:
            with slow_down():
                eu.print_wrapped(self._text)


class DefineVMSpec(task.Task):
    """Defines a vm specification to be."""
    def __init__(self, name):
        super().__init__(provides='vm_spec', name=name)

    def execute(self):
        return {
            'type': 'kvm',
            'disks': 2,
            'vcpu': 1,
            'ips': 1,
            'volumes': 3,
        }


class LocateImages(task.Task):
    """Locates where the vm images are."""
    def __init__(self, name):
        super().__init__(provides='image_locations', name=name)

    def execute(self, vm_spec):
        image_locations = {}
        for i in range(0, vm_spec['disks']):
            url = "http://www.yahoo.com/images/%s" % (i)
            image_locations[url] = "/tmp/%s.img" % (i)
        return image_locations


class DownloadImages(task.Task):
    """Downloads all the vm images."""
    def __init__(self, name):
        super().__init__(provides='download_paths',
                         name=name)

    def execute(self, image_locations):
        for src, loc in image_locations.items():
            with slow_down(1):
                print("Downloading from {} => {}".format(src, loc))
        return sorted(image_locations.values())


class CreateNetworkTpl(task.Task):
    """Generates the network settings file to be placed in the images."""
    SYSCONFIG_CONTENTS = """DEVICE=eth%s
BOOTPROTO=static
IPADDR=%s
ONBOOT=yes"""

    def __init__(self, name):
        super().__init__(provides='network_settings',
                         name=name)

    def execute(self, ips):
        settings = []
        for i, ip in enumerate(ips):
            settings.append(self.SYSCONFIG_CONTENTS % (i, ip))
        return settings


class AllocateIP(task.Task):
    """Allocates the ips for the given vm."""
    def __init__(self, name):
        super().__init__(provides='ips', name=name)

    def execute(self, vm_spec):
        ips = []
        for _i in range(0, vm_spec.get('ips', 0)):
            ips.append("192.168.0.%s" % (random.randint(1, 254)))
        return ips


class WriteNetworkSettings(task.Task):
    """Writes all the network settings into the downloaded images."""
    def execute(self, download_paths, network_settings):
        for j, path in enumerate(download_paths):
            with slow_down(1):
                print("Mounting {} to /tmp/{}".format(path, j))
            for i, setting in enumerate(network_settings):
                filename = ("/tmp/etc/sysconfig/network-scripts/"
                            "ifcfg-eth%s" % (i))
                with slow_down(1):
                    print("Writing to %s" % (filename))
                    print(setting)


class BootVM(task.Task):
    """Fires off the vm boot operation."""
    def execute(self, vm_spec):
        print("Starting vm!")
        with slow_down(1):
            print("Created: %s" % (vm_spec))


class AllocateVolumes(task.Task):
    """Allocates the volumes for the vm."""
    def execute(self, vm_spec):
        volumes = []
        for i in range(0, vm_spec['volumes']):
            with slow_down(1):
                volumes.append("/dev/vda%s" % (i + 1))
                print("Allocated volume %s" % volumes[-1])
        return volumes


class FormatVolumes(task.Task):
    """Formats the volumes for the vm."""
    def execute(self, volumes):
        for v in volumes:
            print("Formatting volume %s" % v)
            with slow_down(1):
                pass
            print("Formatted volume %s" % v)


def create_flow():
    # Setup the set of things to do (mini-nova).
    flow = lf.Flow("root").add(
        PrintText("Starting vm creation.", no_slow=True),
        lf.Flow('vm-maker').add(
            # First create a specification for the final vm to-be.
            DefineVMSpec("define_spec"),
            # This does all the image stuff.
            gf.Flow("img-maker").add(
                LocateImages("locate_images"),
                DownloadImages("download_images"),
            ),
            # This does all the network stuff.
            gf.Flow("net-maker").add(
                AllocateIP("get_my_ips"),
                CreateNetworkTpl("fetch_net_settings"),
                WriteNetworkSettings("write_net_settings"),
            ),
            # This does all the volume stuff.
            gf.Flow("volume-maker").add(
                AllocateVolumes("allocate_my_volumes", provides='volumes'),
                FormatVolumes("volume_formatter"),
            ),
            # Finally boot it all.
            BootVM("boot-it"),
        ),
        # Ya it worked!
        PrintText("Finished vm create.", no_slow=True),
        PrintText("Instance is running!", no_slow=True))
    return flow

eu.print_wrapped("Initializing")

# Setup the persistence & resumption layer.
with eu.get_backend() as backend:

    # Try to find a previously passed in tracking id...
    try:
        book_id, flow_id = sys.argv[2].split("+", 1)
        if not uuidutils.is_uuid_like(book_id):
            book_id = None
        if not uuidutils.is_uuid_like(flow_id):
            flow_id = None
    except (IndexError, ValueError):
        book_id = None
        flow_id = None

    # Set up how we want our engine to run, serial, parallel...
    try:
        executor = futurist.GreenThreadPoolExecutor(max_workers=5)
    except RuntimeError:
        # No eventlet installed, just let the default be used instead.
        executor = None

    # Create/fetch a logbook that will track the workflows work.
    book = None
    flow_detail = None
    if all([book_id, flow_id]):
        # Try to find in a prior logbook and flow detail...
        with contextlib.closing(backend.get_connection()) as conn:
            try:
                book = conn.get_logbook(book_id)
                flow_detail = book.find(flow_id)
            except exc.NotFound:
                pass
    if book is None and flow_detail is None:
        book = models.LogBook("vm-boot")
        with contextlib.closing(backend.get_connection()) as conn:
            conn.save_logbook(book)
        engine = engines.load_from_factory(create_flow,
                                           backend=backend, book=book,
                                           engine='parallel',
                                           executor=executor)
        print("!! Your tracking id is: '{}+{}'".format(
            book.uuid, engine.storage.flow_uuid))
        print("!! Please submit this on later runs for tracking purposes")
    else:
        # Attempt to load from a previously partially completed flow.
        engine = engines.load_from_detail(flow_detail, backend=backend,
                                          engine='parallel', executor=executor)

    # Make me my vm please!
    eu.print_wrapped('Running')
    engine.run()

# How to use.
#
# 1. $ python me.py "sqlite:////tmp/nova.db"
# 2. ctrl-c before this finishes
# 3. Find the tracking id (search for 'Your tracking id is')
# 4. $ python me.py "sqlite:////tmp/cinder.db" "$tracking_id"
# 5. Watch it pick up where it left off.
# 6. Profit!

创建卷（可恢复）

注意

完整源代码位于 resume_volume_create

import hashlib
import logging
import os
import random
import sys
import time

logging.basicConfig(level=logging.ERROR)

self_dir = os.path.abspath(os.path.dirname(__file__))
top_dir = os.path.abspath(os.path.join(os.path.dirname(__file__),
                                       os.pardir,
                                       os.pardir))
sys.path.insert(0, top_dir)
sys.path.insert(0, self_dir)

from oslo_utils import uuidutils

from taskflow import engines
from taskflow.patterns import graph_flow as gf
from taskflow.patterns import linear_flow as lf
from taskflow.persistence import models
from taskflow import task

import example_utils  # noqa

# INTRO: These examples show how a hierarchy of flows can be used to create a
# pseudo-volume in a reliable & resumable manner using taskflow + a miniature
# version of what cinder does while creating a volume (very miniature).


@contextlib.contextmanager
def slow_down(how_long=0.5):
    try:
        yield how_long
    finally:
        print("** Ctrl-c me please!!! **")
        time.sleep(how_long)


def find_flow_detail(backend, book_id, flow_id):
    # NOTE(harlowja): this is used to attempt to find a given logbook with
    # a given id and a given flow details inside that logbook, we need this
    # reference so that we can resume the correct flow (as a logbook tracks
    # flows and a flow detail tracks a individual flow).
    #
    # Without a reference to the logbook and the flow details in that logbook
    # we will not know exactly what we should resume and that would mean we
    # can't resume what we don't know.
    with contextlib.closing(backend.get_connection()) as conn:
        lb = conn.get_logbook(book_id)
        return lb.find(flow_id)


class PrintText(task.Task):
    def __init__(self, print_what, no_slow=False):
        content_hash = hashlib.md5(print_what.encode('utf-8')).hexdigest()[0:8]
        super().__init__(name="Print: %s" % (content_hash))
        self._text = print_what
        self._no_slow = no_slow

    def execute(self):
        if self._no_slow:
            print("-" * (len(self._text)))
            print(self._text)
            print("-" * (len(self._text)))
        else:
            with slow_down():
                print("-" * (len(self._text)))
                print(self._text)
                print("-" * (len(self._text)))


class CreateSpecForVolumes(task.Task):
    def execute(self):
        volumes = []
        for i in range(0, random.randint(1, 10)):
            volumes.append({
                'type': 'disk',
                'location': "/dev/vda%s" % (i + 1),
            })
        return volumes


class PrepareVolumes(task.Task):
    def execute(self, volume_specs):
        for v in volume_specs:
            with slow_down():
                print("Dusting off your hard drive %s" % (v))
            with slow_down():
                print("Taking a well deserved break.")
            print("Your drive %s has been certified." % (v))


# Setup the set of things to do (mini-cinder).
flow = lf.Flow("root").add(
    PrintText("Starting volume create", no_slow=True),
    gf.Flow('maker').add(
        CreateSpecForVolumes("volume_specs", provides='volume_specs'),
        PrintText("I need a nap, it took me a while to build those specs."),
        PrepareVolumes(),
    ),
    PrintText("Finished volume create", no_slow=True))

# Setup the persistence & resumption layer.
with example_utils.get_backend() as backend:
    try:
        book_id, flow_id = sys.argv[2].split("+", 1)
    except (IndexError, ValueError):
        book_id = None
        flow_id = None

    if not all([book_id, flow_id]):
        # If no 'tracking id' (think a fedex or ups tracking id) is provided
        # then we create one by creating a logbook (where flow details are
        # stored) and creating a flow detail (where flow and task state is
        # stored). The combination of these 2 objects unique ids (uuids) allows
        # the users of taskflow to reassociate the workflows that were
        # potentially running (and which may have partially completed) back
        # with taskflow so that those workflows can be resumed (or reverted)
        # after a process/thread/engine has failed in someway.
        book = models.LogBook('resume-volume-create')
        flow_detail = models.FlowDetail("root", uuid=uuidutils.generate_uuid())
        book.add(flow_detail)
        with contextlib.closing(backend.get_connection()) as conn:
            conn.save_logbook(book)
        print("!! Your tracking id is: '{}+{}'".format(book.uuid,
                                                       flow_detail.uuid))
        print("!! Please submit this on later runs for tracking purposes")
    else:
        flow_detail = find_flow_detail(backend, book_id, flow_id)

    # Load and run.
    engine = engines.load(flow,
                          flow_detail=flow_detail,
                          backend=backend, engine='serial')
    engine.run()

# How to use.
#
# 1. $ python me.py "sqlite:////tmp/cinder.db"
# 2. ctrl-c before this finishes
# 3. Find the tracking id (search for 'Your tracking id is')
# 4. $ python me.py "sqlite:////tmp/cinder.db" "$tracking_id"
# 5. Profit!

通过迭代运行引擎

注意

完整源代码位于 run_by_iter

import os
import sys

logging.basicConfig(level=logging.ERROR)

self_dir = os.path.abspath(os.path.dirname(__file__))
top_dir = os.path.abspath(os.path.join(os.path.dirname(__file__),
                                       os.pardir,
                                       os.pardir))
sys.path.insert(0, top_dir)
sys.path.insert(0, self_dir)


from taskflow import engines
from taskflow.patterns import linear_flow as lf
from taskflow import task


# INTRO: This example shows how to run a set of engines at the same time, each
# running in different engines using a single thread of control to iterate over
# each engine (which causes that engine to advanced to its next state during
# each iteration).


class EchoTask(task.Task):
    def execute(self, value):
        print(value)
        return chr(ord(value) + 1)


def make_alphabet_flow(i):
    f = lf.Flow("alphabet_%s" % (i))
    start_value = 'A'
    end_value = 'Z'
    curr_value = start_value
    while ord(curr_value) <= ord(end_value):
        next_value = chr(ord(curr_value) + 1)
        if curr_value != end_value:
            f.add(EchoTask(name="echoer_%s" % curr_value,
                           rebind={'value': curr_value},
                           provides=next_value))
        else:
            f.add(EchoTask(name="echoer_%s" % curr_value,
                           rebind={'value': curr_value}))
        curr_value = next_value
    return f


# Adjust this number to change how many engines/flows run at once.
flow_count = 1
flows = []
for i in range(0, flow_count):
    f = make_alphabet_flow(i + 1)
    flows.append(make_alphabet_flow(i + 1))
engine_iters = []
for f in flows:
    e = engines.load(f)
    e.compile()
    e.storage.inject({'A': 'A'})
    e.prepare()
    engine_iters.append(e.run_iter())
while engine_iters:
    for it in list(engine_iters):
        try:
            print(next(it))
        except StopIteration:
            engine_iters.remove(it)

使用重试控制器控制重试

注意

完整源代码位于 retry_flow

import os
import sys

logging.basicConfig(level=logging.ERROR)

top_dir = os.path.abspath(os.path.join(os.path.dirname(__file__),
                                       os.pardir,
                                       os.pardir))
sys.path.insert(0, top_dir)

import taskflow.engines
from taskflow.patterns import linear_flow as lf
from taskflow import retry
from taskflow import task

# INTRO: In this example we create a retry controller that receives a phone
# directory and tries different phone numbers. The next task tries to call Jim
# using the given number. If it is not a Jim's number, the task raises an
# exception and retry controller takes the next number from the phone
# directory and retries the call.
#
# This example shows a basic usage of retry controllers in a flow.
# Retry controllers allows to revert and retry a failed subflow with new
# parameters.


class CallJim(task.Task):
    def execute(self, jim_number):
        print("Calling jim %s." % jim_number)
        if jim_number != 555:
            raise Exception("Wrong number!")
        else:
            print("Hello Jim!")

    def revert(self, jim_number, **kwargs):
        print("Wrong number, apologizing.")


# Create your flow and associated tasks (the work to be done).
flow = lf.Flow('retrying-linear',
               retry=retry.ParameterizedForEach(
                   rebind=['phone_directory'],
                   provides='jim_number')).add(CallJim())

# Now run that flow using the provided initial data (store below).
taskflow.engines.run(flow, store={'phone_directory': [333, 444, 555, 666]})

分布式执行（简单）

注意

完整源代码位于 wbe_simple_linear

import logging
import os
import sys
import tempfile

top_dir = os.path.abspath(os.path.join(os.path.dirname(__file__),
                                       os.pardir,
                                       os.pardir))
sys.path.insert(0, top_dir)

from taskflow import engines
from taskflow.engines.worker_based import worker
from taskflow.patterns import linear_flow as lf
from taskflow.tests import utils
from taskflow.utils import threading_utils

import example_utils  # noqa

# INTRO: This example walks through a miniature workflow which shows how to
# start up a number of workers (these workers will process task execution and
# reversion requests using any provided input data) and then use an engine
# that creates a set of *capable* tasks and flows (the engine can not create
# tasks that the workers are not able to run, this will end in failure) that
# those workers will run and then executes that workflow seamlessly using the
# workers to perform the actual execution.
#
# NOTE(harlowja): this example simulates the expected larger number of workers
# by using a set of threads (which in this example simulate the remote workers
# that would typically be running on other external machines).

# A filesystem can also be used as the queue transport (useful as simple
# transport type that does not involve setting up a larger mq system). If this
# is false then the memory transport is used instead, both work in standalone
# setups.
USE_FILESYSTEM = False
BASE_SHARED_CONF = {
    'exchange': 'taskflow',
}

# Until https://github.com/celery/kombu/issues/398 is resolved it is not
# recommended to run many worker threads in this example due to the types
# of errors mentioned in that issue.
MEMORY_WORKERS = 2
FILE_WORKERS = 1
WORKER_CONF = {
    # These are the tasks the worker can execute, they *must* be importable,
    # typically this list is used to restrict what workers may execute to
    # a smaller set of *allowed* tasks that are known to be safe (one would
    # not want to allow all python code to be executed).
    'tasks': [
        'taskflow.tests.utils:TaskOneArgOneReturn',
        'taskflow.tests.utils:TaskMultiArgOneReturn'
    ],
}


def run(engine_options):
    flow = lf.Flow('simple-linear').add(
        utils.TaskOneArgOneReturn(provides='result1'),
        utils.TaskMultiArgOneReturn(provides='result2')
    )
    eng = engines.load(flow,
                       store=dict(x=111, y=222, z=333),
                       engine='worker-based', **engine_options)
    eng.run()
    return eng.storage.fetch_all()


if __name__ == "__main__":
    logging.basicConfig(level=logging.ERROR)

    # Setup our transport configuration and merge it into the worker and
    # engine configuration so that both of those use it correctly.
    shared_conf = dict(BASE_SHARED_CONF)

    tmp_path = None
    if USE_FILESYSTEM:
        worker_count = FILE_WORKERS
        tmp_path = tempfile.mkdtemp(prefix='wbe-example-')
        shared_conf.update({
            'transport': 'filesystem',
            'transport_options': {
                'data_folder_in': tmp_path,
                'data_folder_out': tmp_path,
                'polling_interval': 0.1,
            },
        })
    else:
        worker_count = MEMORY_WORKERS
        shared_conf.update({
            'transport': 'memory',
            'transport_options': {
                'polling_interval': 0.1,
            },
        })
    worker_conf = dict(WORKER_CONF)
    worker_conf.update(shared_conf)
    engine_options = dict(shared_conf)
    workers = []
    worker_topics = []

    try:
        # Create a set of workers to simulate actual remote workers.
        print('Running %s workers.' % (worker_count))
        for i in range(0, worker_count):
            worker_conf['topic'] = 'worker-%s' % (i + 1)
            worker_topics.append(worker_conf['topic'])
            w = worker.Worker(**worker_conf)
            runner = threading_utils.daemon_thread(w.run)
            runner.start()
            w.wait()
            workers.append((runner, w.stop))

        # Now use those workers to do something.
        print('Executing some work.')
        engine_options['topics'] = worker_topics
        result = run(engine_options)
        print('Execution finished.')
        # This is done so that the test examples can work correctly
        # even when the keys change order (which will happen in various
        # python versions).
        print("Result = %s" % json.dumps(result, sort_keys=True))
    finally:
        # And cleanup.
        print('Stopping workers.')
        while workers:
            r, stopper = workers.pop()
            stopper()
            r.join()
        if tmp_path:
            example_utils.rm_path(tmp_path)

分布式通知（简单）

注意

完整源代码位于 wbe_event_sender

import os
import string
import sys
import time

top_dir = os.path.abspath(os.path.join(os.path.dirname(__file__),
                                       os.pardir,
                                       os.pardir))
sys.path.insert(0, top_dir)

from taskflow import engines
from taskflow.engines.worker_based import worker
from taskflow.patterns import linear_flow as lf
from taskflow import task
from taskflow.types import notifier
from taskflow.utils import threading_utils

ANY = notifier.Notifier.ANY

# INTRO: These examples show how to use a remote worker's event notification
# attribute to proxy back task event notifications to the controlling process.
#
# In this case a simple set of events is triggered by a worker running a
# task (simulated to be remote by using a kombu memory transport and threads).
# Those events that the 'remote worker' produces will then be proxied back to
# the task that the engine is running 'remotely', and then they will be emitted
# back to the original callbacks that exist in the originating engine
# process/thread. This creates a one-way *notification* channel that can
# transparently be used in-process, outside-of-process using remote workers and
# so-on that allows tasks to signal to its controlling process some sort of
# action that has occurred that the task may need to tell others about (for
# example to trigger some type of response when the task reaches 50% done...).


def event_receiver(event_type, details):
    """This is the callback that (in this example) doesn't do much..."""
    print("Recieved event '%s'" % event_type)
    print("Details = %s" % details)


class EventReporter(task.Task):
    """This is the task that will be running 'remotely' (not really remote)."""

    EVENTS = tuple(string.ascii_uppercase)
    EVENT_DELAY = 0.1

    def execute(self):
        for i, e in enumerate(self.EVENTS):
            details = {
                'leftover': self.EVENTS[i:],
            }
            self.notifier.notify(e, details)
            time.sleep(self.EVENT_DELAY)


BASE_SHARED_CONF = {
    'exchange': 'taskflow',
    'transport': 'memory',
    'transport_options': {
        'polling_interval': 0.1,
    },
}

# Until https://github.com/celery/kombu/issues/398 is resolved it is not
# recommended to run many worker threads in this example due to the types
# of errors mentioned in that issue.
MEMORY_WORKERS = 1
WORKER_CONF = {
    'tasks': [
        # Used to locate which tasks we can run (we don't want to allow
        # arbitrary code/tasks to be ran by any worker since that would
        # open up a variety of vulnerabilities).
        '%s:EventReporter' % (__name__),
    ],
}


def run(engine_options):
    reporter = EventReporter()
    reporter.notifier.register(ANY, event_receiver)
    flow = lf.Flow('event-reporter').add(reporter)
    eng = engines.load(flow, engine='worker-based', **engine_options)
    eng.run()


if __name__ == "__main__":
    logging.basicConfig(level=logging.ERROR)

    # Setup our transport configuration and merge it into the worker and
    # engine configuration so that both of those objects use it correctly.
    worker_conf = dict(WORKER_CONF)
    worker_conf.update(BASE_SHARED_CONF)
    engine_options = dict(BASE_SHARED_CONF)
    workers = []

    # These topics will be used to request worker information on; those
    # workers will respond with their capabilities which the executing engine
    # will use to match pending tasks to a matched worker, this will cause
    # the task to be sent for execution, and the engine will wait until it
    # is finished (a response is received) and then the engine will either
    # continue with other tasks, do some retry/failure resolution logic or
    # stop (and potentially re-raise the remote workers failure)...
    worker_topics = []

    try:
        # Create a set of worker threads to simulate actual remote workers...
        print('Running %s workers.' % (MEMORY_WORKERS))
        for i in range(0, MEMORY_WORKERS):
            # Give each one its own unique topic name so that they can
            # correctly communicate with the engine (they will all share the
            # same exchange).
            worker_conf['topic'] = 'worker-%s' % (i + 1)
            worker_topics.append(worker_conf['topic'])
            w = worker.Worker(**worker_conf)
            runner = threading_utils.daemon_thread(w.run)
            runner.start()
            w.wait()
            workers.append((runner, w.stop))

        # Now use those workers to do something.
        print('Executing some work.')
        engine_options['topics'] = worker_topics
        result = run(engine_options)
        print('Execution finished.')
    finally:
        # And cleanup.
        print('Stopping workers.')
        while workers:
            r, stopper = workers.pop()
            stopper()
            r.join()

分布式 Mandelbrot（复杂）

注意

完整源代码位于 wbe_mandelbrot

输出

代码

import math
import os
import sys

top_dir = os.path.abspath(os.path.join(os.path.dirname(__file__),
                                       os.pardir,
                                       os.pardir))
sys.path.insert(0, top_dir)

from taskflow import engines
from taskflow.engines.worker_based import worker
from taskflow.patterns import unordered_flow as uf
from taskflow import task
from taskflow.utils import threading_utils

# INTRO: This example walks through a workflow that will in parallel compute
# a mandelbrot result set (using X 'remote' workers) and then combine their
# results together to form a final mandelbrot fractal image. It shows a usage
# of taskflow to perform a well-known embarrassingly parallel problem that has
# the added benefit of also being an elegant visualization.
#
# NOTE(harlowja): this example simulates the expected larger number of workers
# by using a set of threads (which in this example simulate the remote workers
# that would typically be running on other external machines).
#
# NOTE(harlowja): to have it produce an image run (after installing pillow):
#
# $ python taskflow/examples/wbe_mandelbrot.py output.png

BASE_SHARED_CONF = {
    'exchange': 'taskflow',
}
WORKERS = 2
WORKER_CONF = {
    # These are the tasks the worker can execute, they *must* be importable,
    # typically this list is used to restrict what workers may execute to
    # a smaller set of *allowed* tasks that are known to be safe (one would
    # not want to allow all python code to be executed).
    'tasks': [
        '%s:MandelCalculator' % (__name__),
    ],
}
ENGINE_CONF = {
    'engine': 'worker-based',
}

# Mandelbrot & image settings...
IMAGE_SIZE = (512, 512)
CHUNK_COUNT = 8
MAX_ITERATIONS = 25


class MandelCalculator(task.Task):
    def execute(self, image_config, mandelbrot_config, chunk):
        """Returns the number of iterations before the computation "escapes".

        Given the real and imaginary parts of a complex number, determine if it
        is a candidate for membership in the mandelbrot set given a fixed
        number of iterations.
        """

        # Parts borrowed from (credit to mark harris and benoît mandelbrot).
        #
        # http://nbviewer.ipython.org/gist/harrism/f5707335f40af9463c43
        def mandelbrot(x, y, max_iters):
            c = complex(x, y)
            z = 0.0j
            for i in range(max_iters):
                z = z * z + c
                if (z.real * z.real + z.imag * z.imag) >= 4:
                    return i
            return max_iters

        min_x, max_x, min_y, max_y, max_iters = mandelbrot_config
        height, width = image_config['size']
        pixel_size_x = (max_x - min_x) / width
        pixel_size_y = (max_y - min_y) / height
        block = []
        for y in range(chunk[0], chunk[1]):
            row = []
            imag = min_y + y * pixel_size_y
            for x in range(0, width):
                real = min_x + x * pixel_size_x
                row.append(mandelbrot(real, imag, max_iters))
            block.append(row)
        return block


def calculate(engine_conf):
    # Subdivide the work into X pieces, then request each worker to calculate
    # one of those chunks and then later we will write these chunks out to
    # an image bitmap file.

    # And unordered flow is used here since the mandelbrot calculation is an
    # example of an embarrassingly parallel computation that we can scatter
    # across as many workers as possible.
    flow = uf.Flow("mandelbrot")

    # These symbols will be automatically given to tasks as input to their
    # execute method, in this case these are constants used in the mandelbrot
    # calculation.
    store = {
        'mandelbrot_config': [-2.0, 1.0, -1.0, 1.0, MAX_ITERATIONS],
        'image_config': {
            'size': IMAGE_SIZE,
        }
    }

    # We need the task names to be in the right order so that we can extract
    # the final results in the right order (we don't care about the order when
    # executing).
    task_names = []

    # Compose our workflow.
    height, _width = IMAGE_SIZE
    chunk_size = int(math.ceil(height / float(CHUNK_COUNT)))
    for i in range(0, CHUNK_COUNT):
        chunk_name = 'chunk_%s' % i
        task_name = "calculation_%s" % i
        # Break the calculation up into chunk size pieces.
        rows = [i * chunk_size, i * chunk_size + chunk_size]
        flow.add(
            MandelCalculator(task_name,
                             # This ensures the storage symbol with name
                             # 'chunk_name' is sent into the tasks local
                             # symbol 'chunk'. This is how we give each
                             # calculator its own correct sequence of rows
                             # to work on.
                             rebind={'chunk': chunk_name}))
        store[chunk_name] = rows
        task_names.append(task_name)

    # Now execute it.
    eng = engines.load(flow, store=store, engine_conf=engine_conf)
    eng.run()

    # Gather all the results and order them for further processing.
    gather = []
    for name in task_names:
        gather.extend(eng.storage.get(name))
    points = []
    for y, row in enumerate(gather):
        for x, color in enumerate(row):
            points.append(((x, y), color))
    return points


def write_image(results, output_filename=None):
    print("Gathered %s results that represents a mandelbrot"
          " image (using %s chunks that are computed jointly"
          " by %s workers)." % (len(results), CHUNK_COUNT, WORKERS))
    if not output_filename:
        return

    # Pillow (the PIL fork) saves us from writing our own image writer...
    try:
        from PIL import Image
    except ImportError as e:
        # To currently get this (may change in the future),
        # $ pip install Pillow
        raise RuntimeError("Pillow is required to write image files: %s" % e)

    # Limit to 255, find the max and normalize to that...
    color_max = 0
    for _point, color in results:
        color_max = max(color, color_max)

    # Use gray scale since we don't really have other colors.
    img = Image.new('L', IMAGE_SIZE, "black")
    pixels = img.load()
    for (x, y), color in results:
        if color_max == 0:
            color = 0
        else:
            color = int((float(color) / color_max) * 255.0)
        pixels[x, y] = color
    img.save(output_filename)


def create_fractal():
    logging.basicConfig(level=logging.ERROR)

    # Setup our transport configuration and merge it into the worker and
    # engine configuration so that both of those use it correctly.
    shared_conf = dict(BASE_SHARED_CONF)
    shared_conf.update({
        'transport': 'memory',
        'transport_options': {
            'polling_interval': 0.1,
        },
    })

    if len(sys.argv) >= 2:
        output_filename = sys.argv[1]
    else:
        output_filename = None

    worker_conf = dict(WORKER_CONF)
    worker_conf.update(shared_conf)
    engine_conf = dict(ENGINE_CONF)
    engine_conf.update(shared_conf)
    workers = []
    worker_topics = []

    print('Calculating your mandelbrot fractal of size %sx%s.' % IMAGE_SIZE)
    try:
        # Create a set of workers to simulate actual remote workers.
        print('Running %s workers.' % (WORKERS))
        for i in range(0, WORKERS):
            worker_conf['topic'] = 'calculator_%s' % (i + 1)
            worker_topics.append(worker_conf['topic'])
            w = worker.Worker(**worker_conf)
            runner = threading_utils.daemon_thread(w.run)
            runner.start()
            w.wait()
            workers.append((runner, w.stop))

        # Now use those workers to do something.
        engine_conf['topics'] = worker_topics
        results = calculate(engine_conf)
        print('Execution finished.')
    finally:
        # And cleanup.
        print('Stopping workers.')
        while workers:
            r, stopper = workers.pop()
            stopper()
            r.join()
    print("Writing image...")
    write_image(results, output_filename=output_filename)


if __name__ == "__main__":
    create_fractal()

作业板生产者/消费者（简单）

注意

完整源代码位于 jobboard_produce_consume_colors

import contextlib
import logging
import os
import random
import sys
import threading
import time

logging.basicConfig(level=logging.ERROR)

top_dir = os.path.abspath(os.path.join(os.path.dirname(__file__),
                                       os.pardir,
                                       os.pardir))
sys.path.insert(0, top_dir)

from zake import fake_client

from taskflow import exceptions as excp
from taskflow.jobs import backends
from taskflow.utils import threading_utils

# In this example we show how a jobboard can be used to post work for other
# entities to work on. This example creates a set of jobs using one producer
# thread (typically this would be split across many machines) and then having
# other worker threads with their own jobboards select work using a given
# filters [red/blue] and then perform that work (and consuming or abandoning
# the job after it has been completed or failed).

# Things to note:
# - No persistence layer is used (or logbook), just the job details are used
#   to determine if a job should be selected by a worker or not.
# - This example runs in a single process (this is expected to be atypical
#   but this example shows that it can be done if needed, for testing...)
# - The iterjobs(), claim(), consume()/abandon() worker workflow.
# - The post() producer workflow.

SHARED_CONF = {
    'path': "/taskflow/jobs",
    'board': 'zookeeper',
}

# How many workers and producers of work will be created (as threads).
PRODUCERS = 3
WORKERS = 5

# How many units of work each producer will create.
PRODUCER_UNITS = 10

# How many units of work are expected to be produced (used so workers can
# know when to stop running and shutdown, typically this would not be a
# a value but we have to limit this example's execution time to be less than
# infinity).
EXPECTED_UNITS = PRODUCER_UNITS * PRODUCERS

# Delay between producing/consuming more work.
WORKER_DELAY, PRODUCER_DELAY = (0.5, 0.5)

# To ensure threads don't trample other threads output.
STDOUT_LOCK = threading.Lock()


def dispatch_work(job):
    # This is where the jobs contained work *would* be done
    time.sleep(1.0)


def safe_print(name, message, prefix=""):
    with STDOUT_LOCK:
        if prefix:
            print("{} {}: {}".format(prefix, name, message))
        else:
            print("{}: {}".format(name, message))


def worker(ident, client, consumed):
    # Create a personal board (using the same client so that it works in
    # the same process) and start looking for jobs on the board that we want
    # to perform.
    name = "W-%s" % (ident)
    safe_print(name, "started")
    claimed_jobs = 0
    consumed_jobs = 0
    abandoned_jobs = 0
    with backends.backend(name, SHARED_CONF.copy(), client=client) as board:
        while len(consumed) != EXPECTED_UNITS:
            favorite_color = random.choice(['blue', 'red'])
            for job in board.iterjobs(ensure_fresh=True, only_unclaimed=True):
                # See if we should even bother with it...
                if job.details.get('color') != favorite_color:
                    continue
                safe_print(name, "'%s' [attempting claim]" % (job))
                try:
                    board.claim(job, name)
                    claimed_jobs += 1
                    safe_print(name, "'%s' [claimed]" % (job))
                except (excp.NotFound, excp.UnclaimableJob):
                    safe_print(name, "'%s' [claim unsuccessful]" % (job))
                else:
                    try:
                        dispatch_work(job)
                        board.consume(job, name)
                        safe_print(name, "'%s' [consumed]" % (job))
                        consumed_jobs += 1
                        consumed.append(job)
                    except Exception:
                        board.abandon(job, name)
                        abandoned_jobs += 1
                        safe_print(name, "'%s' [abandoned]" % (job))
            time.sleep(WORKER_DELAY)
    safe_print(name,
               "finished (claimed %s jobs, consumed %s jobs,"
               " abandoned %s jobs)" % (claimed_jobs, consumed_jobs,
                                        abandoned_jobs), prefix=">>>")


def producer(ident, client):
    # Create a personal board (using the same client so that it works in
    # the same process) and start posting jobs on the board that we want
    # some entity to perform.
    name = "P-%s" % (ident)
    safe_print(name, "started")
    with backends.backend(name, SHARED_CONF.copy(), client=client) as board:
        for i in range(0, PRODUCER_UNITS):
            job_name = "{}-{}".format(name, i)
            details = {
                'color': random.choice(['red', 'blue']),
            }
            job = board.post(job_name, book=None, details=details)
            safe_print(name, "'%s' [posted]" % (job))
            time.sleep(PRODUCER_DELAY)
    safe_print(name, "finished", prefix=">>>")


def main():
    # TODO(harlowja): Hack to make eventlet work right, remove when the
    # following is fixed: https://github.com/eventlet/eventlet/issues/230
    from taskflow.utils import eventlet_utils as _eu  # noqa
    try:
        import eventlet as _eventlet  # noqa
    except ImportError:
        pass

    with contextlib.closing(fake_client.FakeClient()) as c:
        created = []
        for i in range(0, PRODUCERS):
            p = threading_utils.daemon_thread(producer, i + 1, c)
            created.append(p)
            p.start()
        consumed = collections.deque()
        for i in range(0, WORKERS):
            w = threading_utils.daemon_thread(worker, i + 1, c, consumed)
            created.append(w)
            w.start()
        while created:
            t = created.pop()
            t.join()
        # At the end there should be nothing leftover, let's verify that.
        board = backends.fetch('verifier', SHARED_CONF.copy(), client=c)
        board.connect()
        with contextlib.closing(board):
            if board.job_count != 0 or len(consumed) != EXPECTED_UNITS:
                return 1
            return 0


if __name__ == "__main__":
    sys.exit(main())

Conductor 模拟 CI 管道

注意

完整源代码位于 tox_conductor

import itertools
import logging
import os
import shutil
import socket
import sys
import tempfile
import threading
import time

logging.basicConfig(level=logging.ERROR)

top_dir = os.path.abspath(os.path.join(os.path.dirname(__file__),
                                       os.pardir,
                                       os.pardir))
sys.path.insert(0, top_dir)

from oslo_utils import timeutils
from oslo_utils import uuidutils
from zake import fake_client

from taskflow.conductors import backends as conductors
from taskflow import engines
from taskflow.jobs import backends as boards
from taskflow.patterns import linear_flow
from taskflow.persistence import backends as persistence
from taskflow.persistence import models
from taskflow import task
from taskflow.utils import threading_utils

# INTRO: This examples shows how a worker/producer can post desired work (jobs)
# to a jobboard and a conductor can consume that work (jobs) from that jobboard
# and execute those jobs in a reliable & async manner (for example, if the
# conductor were to crash then the job will be released back onto the jobboard
# and another conductor can attempt to finish it, from wherever that job last
# left off).
#
# In this example a in-memory jobboard (and in-memory storage) is created and
# used that simulates how this would be done at a larger scale (it is an
# example after all).

# Restrict how long this example runs for...
RUN_TIME = 5
REVIEW_CREATION_DELAY = 0.5
SCAN_DELAY = 0.1
NAME = "{}_{}".format(socket.getfqdn(), os.getpid())

# This won't really use zookeeper but will use a local version of it using
# the zake library that mimics an actual zookeeper cluster using threads and
# an in-memory data structure.
JOBBOARD_CONF = {
    'board': 'zookeeper://?path=/taskflow/tox/jobs',
}


class RunReview(task.Task):
    # A dummy task that clones the review and runs tox...

    def _clone_review(self, review, temp_dir):
        print("Cloning review '{}' into {}".format(review['id'], temp_dir))

    def _run_tox(self, temp_dir):
        print("Running tox in %s" % temp_dir)

    def execute(self, review, temp_dir):
        self._clone_review(review, temp_dir)
        self._run_tox(temp_dir)


class MakeTempDir(task.Task):
    # A task that creates and destroys a temporary dir (on failure).
    #
    # It provides the location of the temporary dir for other tasks to use
    # as they see fit.

    default_provides = 'temp_dir'

    def execute(self):
        return tempfile.mkdtemp()

    def revert(self, *args, **kwargs):
        temp_dir = kwargs.get(task.REVERT_RESULT)
        if temp_dir:
            shutil.rmtree(temp_dir)


class CleanResources(task.Task):
    # A task that cleans up any workflow resources.

    def execute(self, temp_dir):
        print("Removing %s" % temp_dir)
        shutil.rmtree(temp_dir)


def review_iter():
    """Makes reviews (never-ending iterator/generator)."""
    review_id_gen = itertools.count(0)
    while True:
        review_id = next(review_id_gen)
        review = {
            'id': review_id,
        }
        yield review


# The reason this is at the module namespace level is important, since it must
# be accessible from a conductor dispatching an engine, if it was a lambda
# function for example, it would not be reimportable and the conductor would
# be unable to reference it when creating the workflow to run.
def create_review_workflow():
    """Factory method used to create a review workflow to run."""
    f = linear_flow.Flow("tester")
    f.add(
        MakeTempDir(name="maker"),
        RunReview(name="runner"),
        CleanResources(name="cleaner")
    )
    return f


def generate_reviewer(client, saver, name=NAME):
    """Creates a review producer thread with the given name prefix."""
    real_name = "%s_reviewer" % name
    no_more = threading.Event()
    jb = boards.fetch(real_name, JOBBOARD_CONF,
                      client=client, persistence=saver)

    def make_save_book(saver, review_id):
        # Record what we want to happen (sometime in the future).
        book = models.LogBook("book_%s" % review_id)
        detail = models.FlowDetail("flow_%s" % review_id,
                                   uuidutils.generate_uuid())
        book.add(detail)
        # Associate the factory method we want to be called (in the future)
        # with the book, so that the conductor will be able to call into
        # that factory to retrieve the workflow objects that represent the
        # work.
        #
        # These args and kwargs *can* be used to save any specific parameters
        # into the factory when it is being called to create the workflow
        # objects (typically used to tell a factory how to create a unique
        # workflow that represents this review).
        factory_args = ()
        factory_kwargs = {}
        engines.save_factory_details(detail, create_review_workflow,
                                     factory_args, factory_kwargs)
        with contextlib.closing(saver.get_connection()) as conn:
            conn.save_logbook(book)
            return book

    def run():
        """Periodically publishes 'fake' reviews to analyze."""
        jb.connect()
        review_generator = review_iter()
        with contextlib.closing(jb):
            while not no_more.is_set():
                review = next(review_generator)
                details = {
                    'store': {
                        'review': review,
                    },
                }
                job_name = "{}_{}".format(real_name, review['id'])
                print("Posting review '%s'" % review['id'])
                jb.post(job_name,
                        book=make_save_book(saver, review['id']),
                        details=details)
                time.sleep(REVIEW_CREATION_DELAY)

    # Return the unstarted thread, and a callback that can be used
    # shutdown that thread (to avoid running forever).
    return (threading_utils.daemon_thread(target=run), no_more.set)


def generate_conductor(client, saver, name=NAME):
    """Creates a conductor thread with the given name prefix."""
    real_name = "%s_conductor" % name
    jb = boards.fetch(name, JOBBOARD_CONF,
                      client=client, persistence=saver)
    conductor = conductors.fetch("blocking", real_name, jb,
                                 engine='parallel', wait_timeout=SCAN_DELAY)

    def run():
        jb.connect()
        with contextlib.closing(jb):
            conductor.run()

    # Return the unstarted thread, and a callback that can be used
    # shutdown that thread (to avoid running forever).
    return (threading_utils.daemon_thread(target=run), conductor.stop)


def main():
    # Need to share the same backend, so that data can be shared...
    persistence_conf = {
        'connection': 'memory',
    }
    saver = persistence.fetch(persistence_conf)
    with contextlib.closing(saver.get_connection()) as conn:
        # This ensures that the needed backend setup/data directories/schema
        # upgrades and so on... exist before they are attempted to be used...
        conn.upgrade()
    fc1 = fake_client.FakeClient()
    # Done like this to share the same client storage location so the correct
    # zookeeper features work across clients...
    fc2 = fake_client.FakeClient(storage=fc1.storage)
    entities = [
        generate_reviewer(fc1, saver),
        generate_conductor(fc2, saver),
    ]
    for t, stopper in entities:
        t.start()
    try:
        watch = timeutils.StopWatch(duration=RUN_TIME)
        watch.start()
        while not watch.expired():
            time.sleep(0.1)
    finally:
        for t, stopper in reversed(entities):
            stopper()
            t.join()


if __name__ == '__main__':
    main()

Conductor 运行 99 瓶啤酒歌曲请求

注意

完整源代码位于 99_bottles

import functools
import logging
import os
import sys
import time
import traceback

from kazoo import client

top_dir = os.path.abspath(os.path.join(os.path.dirname(__file__),
                                       os.pardir,
                                       os.pardir))
sys.path.insert(0, top_dir)

from taskflow.conductors import backends as conductor_backends
from taskflow import engines
from taskflow.jobs import backends as job_backends
from taskflow import logging as taskflow_logging
from taskflow.patterns import linear_flow as lf
from taskflow.persistence import backends as persistence_backends
from taskflow.persistence import models
from taskflow import task

from oslo_utils import timeutils
from oslo_utils import uuidutils

# Instructions!
#
# 1. Install zookeeper (or change host listed below)
# 2. Download this example, place in file '99_bottles.py'
# 3. Run `python 99_bottles.py p` to place a song request onto the jobboard
# 4. Run `python 99_bottles.py c` a few times (in different shells)
# 5. On demand kill previously listed processes created in (4) and watch
#    the work resume on another process (and repeat)
# 6. Keep enough workers alive to eventually finish the song (if desired).

ME = os.getpid()
ZK_HOST = "localhost:2181"
JB_CONF = {
    'hosts': ZK_HOST,
    'board': 'zookeeper',
    'path': '/taskflow/99-bottles-demo',
}
PERSISTENCE_URI = r"sqlite:////tmp/bottles.db"
TAKE_DOWN_DELAY = 1.0
PASS_AROUND_DELAY = 3.0
HOW_MANY_BOTTLES = 99


class TakeABottleDown(task.Task):
    def execute(self, bottles_left):
        sys.stdout.write('Take one down, ')
        sys.stdout.flush()
        time.sleep(TAKE_DOWN_DELAY)
        return bottles_left - 1


class PassItAround(task.Task):
    def execute(self):
        sys.stdout.write('pass it around, ')
        sys.stdout.flush()
        time.sleep(PASS_AROUND_DELAY)


class Conclusion(task.Task):
    def execute(self, bottles_left):
        sys.stdout.write('%s bottles of beer on the wall...\n' % bottles_left)
        sys.stdout.flush()


def make_bottles(count):
    # This is the function that will be called to generate the workflow
    # and will also be called to regenerate it on resumption so that work
    # can continue from where it last left off...

    s = lf.Flow("bottle-song")

    take_bottle = TakeABottleDown("take-bottle-%s" % count,
                                  inject={'bottles_left': count},
                                  provides='bottles_left')
    pass_it = PassItAround("pass-%s-around" % count)
    next_bottles = Conclusion("next-bottles-%s" % (count - 1))
    s.add(take_bottle, pass_it, next_bottles)

    for bottle in reversed(list(range(1, count))):
        take_bottle = TakeABottleDown("take-bottle-%s" % bottle,
                                      provides='bottles_left')
        pass_it = PassItAround("pass-%s-around" % bottle)
        next_bottles = Conclusion("next-bottles-%s" % (bottle - 1))
        s.add(take_bottle, pass_it, next_bottles)

    return s


def run_conductor(only_run_once=False):
    # This continuously runs consumers until its stopped via ctrl-c or other
    # kill signal...
    event_watches = {}

    # This will be triggered by the conductor doing various activities
    # with engines, and is quite nice to be able to see the various timing
    # segments (which is useful for debugging, or watching, or figuring out
    # where to optimize).
    def on_conductor_event(cond, event, details):
        print("Event '%s' has been received..." % event)
        print("Details = %s" % details)
        if event.endswith("_start"):
            w = timeutils.StopWatch()
            w.start()
            base_event = event[0:-len("_start")]
            event_watches[base_event] = w
        if event.endswith("_end"):
            base_event = event[0:-len("_end")]
            try:
                w = event_watches.pop(base_event)
                w.stop()
                print("It took %0.3f seconds for event '%s' to finish"
                      % (w.elapsed(), base_event))
            except KeyError:
                pass
        if event == 'running_end' and only_run_once:
            cond.stop()

    print("Starting conductor with pid: %s" % ME)
    my_name = "conductor-%s" % ME
    persist_backend = persistence_backends.fetch(PERSISTENCE_URI)
    with contextlib.closing(persist_backend):
        with contextlib.closing(persist_backend.get_connection()) as conn:
            conn.upgrade()
        job_backend = job_backends.fetch(my_name, JB_CONF,
                                         persistence=persist_backend)
        job_backend.connect()
        with contextlib.closing(job_backend):
            cond = conductor_backends.fetch('blocking', my_name, job_backend,
                                            persistence=persist_backend)
            on_conductor_event = functools.partial(on_conductor_event, cond)
            cond.notifier.register(cond.notifier.ANY, on_conductor_event)
            # Run forever, and kill -9 or ctrl-c me...
            try:
                cond.run()
            finally:
                cond.stop()
                cond.wait()


def run_poster():
    # This just posts a single job and then ends...
    print("Starting poster with pid: %s" % ME)
    my_name = "poster-%s" % ME
    persist_backend = persistence_backends.fetch(PERSISTENCE_URI)
    with contextlib.closing(persist_backend):
        with contextlib.closing(persist_backend.get_connection()) as conn:
            conn.upgrade()
        job_backend = job_backends.fetch(my_name, JB_CONF,
                                         persistence=persist_backend)
        job_backend.connect()
        with contextlib.closing(job_backend):
            # Create information in the persistence backend about the
            # unit of work we want to complete and the factory that
            # can be called to create the tasks that the work unit needs
            # to be done.
            lb = models.LogBook("post-from-%s" % my_name)
            fd = models.FlowDetail("song-from-%s" % my_name,
                                   uuidutils.generate_uuid())
            lb.add(fd)
            with contextlib.closing(persist_backend.get_connection()) as conn:
                conn.save_logbook(lb)
            engines.save_factory_details(fd, make_bottles,
                                         [HOW_MANY_BOTTLES], {},
                                         backend=persist_backend)
            # Post, and be done with it!
            jb = job_backend.post("song-from-%s" % my_name, book=lb)
            print("Posted: %s" % jb)
            print("Goodbye...")


def main_local():
    # Run locally typically this is activating during unit testing when all
    # the examples are made sure to still function correctly...
    global TAKE_DOWN_DELAY
    global PASS_AROUND_DELAY
    global JB_CONF
    # Make everything go much faster (so that this finishes quickly).
    PASS_AROUND_DELAY = 0.01
    TAKE_DOWN_DELAY = 0.01
    JB_CONF['path'] = JB_CONF['path'] + "-" + uuidutils.generate_uuid()
    run_poster()
    run_conductor(only_run_once=True)


def check_for_zookeeper(timeout=1):
    sys.stderr.write("Testing for the existence of a zookeeper server...\n")
    sys.stderr.write("Please wait....\n")
    with contextlib.closing(client.KazooClient()) as test_client:
        try:
            test_client.start(timeout=timeout)
        except test_client.handler.timeout_exception:
            sys.stderr.write("Zookeeper is needed for running this example!\n")
            traceback.print_exc()
            return False
        else:
            test_client.stop()
            return True


def main():
    if not check_for_zookeeper():
        return
    if len(sys.argv) == 1:
        main_local()
    elif sys.argv[1] in ('p', 'c'):
        if sys.argv[-1] == "v":
            logging.basicConfig(level=taskflow_logging.TRACE)
        else:
            logging.basicConfig(level=logging.ERROR)
        if sys.argv[1] == 'p':
            run_poster()
        else:
            run_conductor()
    else:
        sys.stderr.write("%s p|c (v?)\n" % os.path.basename(sys.argv[0]))


if __name__ == '__main__':
    main()
